Anritsu S362E Site Master Handheld Cable and Antenna Analyzer with Integrated Spectrum Analyzer and 2 MHz to 6 GHz Frequency Range
Anritsu S362E Site Master Handheld Cable and Antenna Analyzer with Integrated Spectrum Analyzer and 2 MHz to 6 GHz Frequency Range
Anritsu S362E Site Master Handheld Cable and Antenna Analyzer with Integrated Spectrum Analyzer and 2 MHz to 6 GHz Frequency Range
Anritsu S362E Site Master Handheld Cable and Antenna Analyzer with Integrated Spectrum Analyzer and 2 MHz to 6 GHz Frequency Range
Anritsu S362E Site Master Handheld Cable and Antenna Analyzer with Integrated Spectrum Analyzer and 2 MHz to 6 GHz Frequency Range
Anritsu S362E Site Master Handheld Cable and Antenna Analyzer with Integrated Spectrum Analyzer and 2 MHz to 6 GHz Frequency Range
Anritsu S362E Site Master Handheld Cable and Antenna Analyzer with Integrated Spectrum Analyzer and 2 MHz to 6 GHz Frequency Range
Anritsu S362E Site Master Handheld Cable and Antenna Analyzer with Integrated Spectrum Analyzer and 2 MHz to 6 GHz Frequency Range
Specifications
Brand Name :
Anritsu
Model Number :
S362E
Place of Origin :
USA
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
in stock
Packaging Details :
carton
Product name :
Antenna Analyzer with Spectrum Analyzer
Frequency :
2 MHz to 6 GHz
Warranty :
one month
Condition :
Pre-Owned
Functions :
Tested, in Full Working Conditions
Bandwidth :
10 Hz to 3 MH
Description
Anritsu S362E Site Master Handheld Cable and Antenna Analyzer with Spectrum Analyzer
Product Overview

The Next Generation Anritsu Site Master represents a fusion of cutting-edge technology, customer-driven innovation, and decades of expertise in test and measurement solutions. It seamlessly integrates cable and antenna analysis with spectrum analysis and monitoring functionalities, offering a comprehensive testing solution for professionals across various industries. From telecommunications and broadcasting to aerospace and defense, the Site Master cable and antenna analyzer with integrated spectrum analyzer caters to a wide range of applications, including DAS, satellite monitoring, interference analysis, and installation and maintenance tasks.

  • Return Loss, Cable Loss, VSWR, Distance-To-Fault
  • Phase, 2-port Transmission Measurements
  • Spectrum Analyzer, Interference Analyzer, High Accuracy Power Meter
  • Channel Scanner, GPS, AM/FM/PM Analyzer
  • Field-proven design: Four-hour battery life, rugged, compact, lightweight, daylight viewable display
  • Intuitive menu-driven touch screen user interface
  • USB connectivity, built-in touch screen keyboard
Cable and Antenna Analyzer Features
  • Measurements: RL, VSWR, Cable Loss, DTF, Phase
  • 2-port Transmission Measurement: High/Low Power
  • Sweep Speed: 1 ms/data point, typical
  • DTF Time Delay
  • Display: Single or Dual Measurement Touchscreen
  • Calibration: OSL, InstaCal™, and FlexCal™
  • Bias Tee: 32 V internal
Spectrum and Interference Analyzer Features
  • Measurements: Occupied Bandwidth, Channel Power, ACPR, C/I
  • Interference Analyzer: Spectrogram, Signal Strength, RSSI, Signal ID, Interference Mapping
  • Dynamic Range: > 95 dB in 10 Hz RBW
  • DANL: -152 dBm in 10 Hz RBW
  • Phase Noise: -100 dBc/Hz max @ 10 kHz offset at 1 GHz
  • Frequency Accuracy: < ± 50 ppb with GPS On
Available Options
Option Code Description
0010 Variable Bias Tee, +12 to +24V Variable (1V steps)
0019 High Accuracy Power Meter
0021 2-Port Transmission Measurement
0025 Interference Analyzer
0027 Channel Scanner
0028 CW Signal Generator
0029 Power Meter
0031 GPS Receiver
0090 Gated Sweep
0411 Ethernet Connectivity
0419 PIM Analyzer
0431 Coverage Mapping
0509 AM/FM/PM Analyzer
DIN-ADAPT-Kit DIN 7/16 Adapter Kit
OSLN50-1 Precision Open/Short/Load, N (m), 6GHz
TUFFGRIP Cable Tuff Grip Cable, DC - 6 GHz, N/(m) to N(f)
Frequently Asked Questions
1. Can you ship order to Canada or Australia?
Yes, we can. We send orders worldwide.
2. What delivery method do you use? and delivery time?
We can ship by EMS, DHL, FedEx, UPS, TNT with tracking number. Usual delivery time is 4-7 workdays.
3. What is your payment term?
100% T/T payment before shipment.
4. How can I ask any other question?
You can contact us online or leave us messages below.
Product Images
Anritsu S362E Site Master Handheld Cable and Antenna Analyzer with Integrated Spectrum Analyzer and 2 MHz to 6 GHz Frequency Range Anritsu S362E Site Master Handheld Cable and Antenna Analyzer with Integrated Spectrum Analyzer and 2 MHz to 6 GHz Frequency Range Anritsu S362E Site Master Handheld Cable and Antenna Analyzer with Integrated Spectrum Analyzer and 2 MHz to 6 GHz Frequency Range Anritsu S362E Site Master Handheld Cable and Antenna Analyzer with Integrated Spectrum Analyzer and 2 MHz to 6 GHz Frequency Range
