Rohde & Schwarz CMA180 Radio Test Set with 0.1 MHz to 3 GHz Frequency, I/Q Recording and Playback, and Analog and Digital Testing
Rohde & Schwarz CMA180 Radio Test Set with 0.1 MHz to 3 GHz Frequency, I/Q Recording and Playback, and Analog and Digital Testing
Rohde & Schwarz CMA180 Radio Test Set with 0.1 MHz to 3 GHz Frequency, I/Q Recording and Playback, and Analog and Digital Testing
Rohde & Schwarz CMA180 Radio Test Set with 0.1 MHz to 3 GHz Frequency, I/Q Recording and Playback, and Analog and Digital Testing
Rohde & Schwarz CMA180 Radio Test Set with 0.1 MHz to 3 GHz Frequency, I/Q Recording and Playback, and Analog and Digital Testing
Rohde & Schwarz CMA180 Radio Test Set with 0.1 MHz to 3 GHz Frequency, I/Q Recording and Playback, and Analog and Digital Testing
Rohde & Schwarz CMA180 Radio Test Set with 0.1 MHz to 3 GHz Frequency, I/Q Recording and Playback, and Analog and Digital Testing
Rohde & Schwarz CMA180 Radio Test Set with 0.1 MHz to 3 GHz Frequency, I/Q Recording and Playback, and Analog and Digital Testing
Rohde & Schwarz CMA180 Radio Test Set with 0.1 MHz to 3 GHz Frequency, I/Q Recording and Playback, and Analog and Digital Testing
Rohde & Schwarz CMA180 Radio Test Set with 0.1 MHz to 3 GHz Frequency, I/Q Recording and Playback, and Analog and Digital Testing
Specifications
Brand Name :
R&S
Model Number :
CMA180
Place of Origin :
Germany
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
in stock
Product name :
Radio Test Set
Condition :
Pre-Owned
Functions :
Tested, in Full Working Conditions
Frequency :
100 kHz to 3 GHz
Analog testing: :
AM, FM, PM, SSB, CW
Description
CMA180 Radio Test Set Rohde & Schwarz - I/Q Recording and Playback 0.1 MHz to 3 GHz
Product Overview

The R&S Rohde And Schwarz CMA180 is a comprehensive radiocommunications tester for radio systems in the 100 kHz to 3 GHz range. Built on advanced digital signal processing technology, it offers intuitive operation and efficient measurement capabilities ideal for comprehensive radio testing applications.

The CMA180 demodulates and modulates all common analog RF signals, making it perfect for both transmitter and receiver testing. It supports audio signals from internal generators or external sources for comprehensive receiver testing, while demodulated audio signals from devices under test are analyzed through analog or digital inputs.

Beyond analog signal analysis, the CMA180 supports modern digital modulations including DMR, APCO P25, dPMR, NXDN, TETRA, and LTE, making it suitable for testing state-of-the-art multimode radios. The integrated digital signal generator and analyzer provide complete digital receiver and transmitter measurement capabilities.

Key Specifications
  • Frequency Range: 0.1 MHz to 3 GHz
  • Digital Standards: DMR, P25, NXDN, TETRA, POCSAG, Zigbee
  • Analog Testing: AM, FM, PM, SSB, CW
  • Avionics: ILS, VOR, MB generator and VOIP ED-137B/C support
  • I/Q Recording and Playback
Available Options
Option Code Description
CMA-B110D Baseband generator, 4 Gbyte memory
CMA-B612A IEC/IEEE bus interface
CMA-B690A OCXO reference oscillator
CMA-B690M OCXO reference oscillator, high-performance
CMA-B060A Battery compartment
CMA-K120 Signal analyzer (SA), tracking generator (TG), oscilloscope (scope)
CMA-K130 ILS/VOR generator
CMA-K220 I/Q recorder
CMA-K610 VoIP support in line with EUROCAE ED-137B/C
CMA-K611 VoIP delay measurements
CMA-KT051 Analog radio tests
CMA-KT052 Analog radio tests, advanced
CMA-KT061 Battery life test
CMA-KT130 VOR/ILS tests
CMA-KT200 Digital tests (DMR/APCO/NXDN)
CMA-KT410 R&S Series4100 radio test
CMA-KT420 R&S Series4200 radio test
CMA-KT440 R&S Series4400 radio test
CMA-KT520 R&S Series5200 radio test
CMA-KT610 VoIP support
Frequently Asked Questions
Can you ship orders to Canada or Australia?

Yes, we can. We send orders worldwide.

What delivery method do you use and what is the delivery time?

We can ship by EMS, DHL, FedEx, UPS, TNT with tracking number. Usual delivery time is 4-7 workdays.

What is your payment term?

100% T/T payment before shipment.

How can I ask any other question?

You can contact us online or leave us messages below.
