Keysight 8920A RF Communications Test Set with 0.4 - 1000 MHz Frequency Range and 928 kbytes Memory
Keysight 8920A RF Communications Test Set with 0.4 - 1000 MHz Frequency Range and 928 kbytes Memory
Keysight 8920A RF Communications Test Set with 0.4 - 1000 MHz Frequency Range and 928 kbytes Memory
Keysight 8920A RF Communications Test Set with 0.4 - 1000 MHz Frequency Range and 928 kbytes Memory
Keysight 8920A RF Communications Test Set with 0.4 - 1000 MHz Frequency Range and 928 kbytes Memory
Keysight 8920A RF Communications Test Set with 0.4 - 1000 MHz Frequency Range and 928 kbytes Memory
Keysight 8920A RF Communications Test Set with 0.4 - 1000 MHz Frequency Range and 928 kbytes Memory
Keysight 8920A RF Communications Test Set with 0.4 - 1000 MHz Frequency Range and 928 kbytes Memory
Keysight 8920A RF Communications Test Set with 0.4 - 1000 MHz Frequency Range and 928 kbytes Memory
Keysight 8920A RF Communications Test Set with 0.4 - 1000 MHz Frequency Range and 928 kbytes Memory
Specifications
Brand Name :
Keysight (Agilent)
Model Number :
8920A
Place of Origin :
Malaysia
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
in stock
Product name :
RF Communications Test Set
Frequency :
250 kHz to 1000 MHz
User memory :
928 kbytes standard
Memory cards :
PCMCIA
Testing :
Accuracy for testing
Communications systems :
Improving throughput and quality
Description
Keysight (Agilent) 8920A 0.4 - 1000 MHz RF Communications Test Set
Product Overview
The 8920A RF Communications Test Set is a full-feature, one-box test set designed to meet the communication test needs of both service and manufacturing environments. This comprehensive instrument combines multiple functions including signal generator, audio generator, RF analyzer, AF analyzer, oscilloscope, spectrum analyzer, tracking generator, signaling encoder/decoder, and DC current meter - all in one compact unit.
Frequency Coverage: 250kHz to 1GHz
Tracking Generator: 400kHz to 1GHz
Keysight 8920A RF Communications Test Set with 0.4 - 1000 MHz Frequency Range and 928 kbytes Memory Keysight 8920A RF Communications Test Set with 0.4 - 1000 MHz Frequency Range and 928 kbytes Memory Keysight 8920A RF Communications Test Set with 0.4 - 1000 MHz Frequency Range and 928 kbytes Memory
Available Options
Option Code Description
001High Stability Timebase
002Spectrum Analyzer w/Tracking Generator
003HPIB/RS232/DC Current Meas
004Tone/Digital Signaling
005512 kbytes extended RAM
007Low-Level RF Power Measurement
008Cellular Mobile RF Power Measurement Range
009Electronic Attenuator Input Option S/N >3650 30Mhz low end
010400 Hz High Pass Filter
011CCITT Weighting Filter
0124 KHZ Bandpass Filter
013C-Message Weighted Filter
0146kHz Bandpass Filter
016High-Level RF Power Measurement
019Variable Frequency Notch Filter
020Radio Interface Card
031No Handles
050Dual-Mode Rear Panel Connectors
055Mechanical Attenuator S/N >3650 400KHz low end
0B0Do not include manuals
0B1Add Manual Set
0BPOperator Training Video Tape (VHS/NTSC)
0BQOperator Training Video Tape (VHS/PAL)
0BZOperator Training Video Tape (VHS/SECAM)
0Q8Factory Delivered Service Training
102Spectrum Analyzer with Tracking Generator and ACP
103DC Current Sensing and HP-IB, RS-232, and Parallel Input/Output
1CMRackmount Kit
8ZEFactory Refurbished
908Rack Flange Kit for Use without Handles
910Additional operating and service manual
915Adds Assembly Level Repair Manual
C2X2x Calibration Service Agreement
C3X3x Calibration Service Agreement
G05
G27
G29
G30
G49
H04Signal Meter To Unit
H08
H13
H28
K04
R01Retrofit kit for Option 001
R02Retrofit kit for Option 002
R03Retrofit kit for Option 003
R04Retrofit kit for Option 004
R05Retrofit kit for Option 005
R07Retrofit kit for Option 007
R08Retrofit kit for Option 008
R10Retrofit kit for Option 010
R11Retrofit kit for Option 011
R12Retrofit kit for Option 012
R13Retrofit kit for Option 013
R14Retrofit kit for Option 014
R16Retrofit kit for option 016
R19Retrofit kit for Option 019
R20Retrofit kit for Option 020
R24Extended 24 Month Warranty
R36Extended 36 Month Warranty
R404 MB memory Retrofit Kit
R50Retrofit kit for Option 050
R58Firmware Upgrade Kit
R93Retrofit kit for Option 103
R98Firmware Upgrade Kit
RC24Extended 24 Month Warranty & 2x Calibration Service Agreement
RC36Extended 36 Month Warranty & 3x Calibration Service Agreement
UK6Commercial calibration with test results data
