Tektronix DSA70804B 8 GHz Digital Serial Analyzer 25 GS/s 4 Channel

Product Overview

The Tektronix DSA70804B is an 8 GHz Digital Serial Analyzer from the renowned DSA70000 Series, purpose-built for high-speed serial design validation and compliance testing. With 25 GS/s real-time sampling across 4 channels and an advanced jitter and eye diagram analysis package, it provides industry-leading measurement capabilities for engineers working on USB, HDMI, Ethernet, PCIe, and other high-speed serial interfaces.

Key Features & Specifications

  • Bandwidth: 8 GHz on all 4 channels
  • Sample Rate: 25 GS/s real-time on all 4 channels
  • Channels: 4 analog channels
  • Record Length: Up to 250 Megasamples per channel
  • DPOJET Jitter Analysis: Advanced jitter decomposition (TJ, RJ, DJ, PJ), eye diagram with BER contour, and bathtub curve analysis
  • Compliance Testing Ready: Supports USB 2.0, HDMI, Ethernet (10/100/1000BASE-T), and PCIe compliance test suites
  • Pinpoint Triggering: Over 1,400 trigger combinations with serial pattern triggering up to 5 Gbps
  • DPX Fast Acquisition: >300,000 wfms/s capture rate for rapid anomaly detection
  • Serial Data Link Analysis (SDLA): De-embed, equalize, and simulate serial channels
  • Search & Mark: Automated waveform pattern search across deep memory
  • 12.1-inch Color Touch Screen: High-definition display with intuitive multi-touch gestures

Jitter & Eye Diagram Analysis

Equipped with DPOJET Advanced analysis tools, this DSA70804B delivers:
