Rohde Schwarz ESR3 EMI Test Receiver CISPR 16-1-1 Compliant with 9 kHz to 3.6 GHz Frequency Range and Built-in Preselection
Rohde Schwarz ESR3 EMI Test Receiver CISPR 16-1-1 Compliant with 9 kHz to 3.6 GHz Frequency Range and Built-in Preselection
Rohde Schwarz ESR3 EMI Test Receiver CISPR 16-1-1 Compliant with 9 kHz to 3.6 GHz Frequency Range and Built-in Preselection
Rohde Schwarz ESR3 EMI Test Receiver CISPR 16-1-1 Compliant with 9 kHz to 3.6 GHz Frequency Range and Built-in Preselection
Rohde Schwarz ESR3 EMI Test Receiver CISPR 16-1-1 Compliant with 9 kHz to 3.6 GHz Frequency Range and Built-in Preselection
Rohde Schwarz ESR3 EMI Test Receiver CISPR 16-1-1 Compliant with 9 kHz to 3.6 GHz Frequency Range and Built-in Preselection
Specifications
Place of Origin :
Germany
Price :
Negotiation
Displayed Noise Level :
<-155 dBm/Hz (typical)
Resolution Bandwidth :
10 Hz to 10 MHz
Certification :
CE, CISPR 16-1-1, ISO 9001:2015
Payment Terms :
T/T,L/C,PayPal,Western Union
Packaging Details :
Original Rohde & Schwarz packaging with anti-static protection, export-grade wooden crate with shock-proof foam inserts
Delivery Time :
5-7 working days for stock, 3-5 weeks for backorder
RF Input :
50 Ω, N-type female
Supply Ability :
in stock
Dimensions :
462 x 197 x 504 mm
Brand Name :
Rohde & Schwarz
MOQ :
1 Set
Display :
10.1-inch WXGA touchscreen
Model Number :
ESR3
Weight :
14 kg (30.9 lb)
Description
Rohde Schwarz ESR3 EMI Test Receiver CISPR 16-1-1 Compliant 9 kHz to 3.6 GHz Preselection Spectrum Analysis
Rohde & Schwarz ESR3 EMI Test Receiver
Full CISPR 16-1-1 Compliance
Certified EMI measurements per CISPR 16-1-1, MIL-STD-461, and FCC Part 15 standards
Built-in Preselection
Tracking preselector suppresses out-of-band signals for accurate measurements in high-ambient environments
Spectrum Analysis Mode
Dual-function as both EMI receiver and real-time spectrum analyzer for comprehensive EMC diagnostics
Intuitive Touchscreen
10.1-inch WXGA touchscreen with streamlined EMC measurement workflows for fast setup and testing
Product Overview
The Rohde & Schwarz ESR3 is a professional EMI test receiver designed for full-compliance and pre-compliance EMC testing across the 9 kHz to 3.6 GHz frequency range. Fully compliant with CISPR 16-1-1, it integrates a built-in tracking preselector that effectively rejects strong out-of-band signals, ensuring accurate and repeatable measurements even in high-noise environments. The instrument combines the functionality of a precision EMI receiver with a real-time spectrum analyzer, enabling engineers to quickly identify, diagnose, and resolve EMI issues. Equipped with a full suite of detectors (Peak, Average, Quasi-Peak, CISPR-Average, RMS-Average) and a user-friendly 10.1-inch touchscreen, the ESR3 streamlines EMC testing workflows in R&D laboratories, compliance test houses, and production line environments.
Applications
  • EMC pre-compliance and full-compliance conducted emissions testing
  • Radiated emissions measurement with antenna and LISN accessories
  • MIL-STD-461 and FCC Part 15 regulatory testing
  • Component-level EMI debugging and diagnostics
  • Production line EMC quality assurance
  • Automotive EMC testing per CISPR 25
  • Medical device electromagnetic compatibility verification
Technical Specifications
Parameter Specification
Frequency Range 9 kHz to 3.6 GHz
Standard Compliance CISPR 16-1-1, MIL-STD-461, FCC Part 15
Resolution Bandwidth 10 Hz to 10 MHz
DANL (Typical) <-155 dBm/Hz
Preselection Built-in tracking preselector
Detectors Peak, Average, Quasi-Peak, CISPR-Average, RMS-Average
RF Input 50 Ω, N-type female
Display 10.1-inch WXGA touchscreen
Weight 14 kg (30.9 lb)
Dimensions (H x W x D) 462 x 197 x 504 mm
Warranty 1 Year Standard
