Pre-Owned 20 GHz Anritsu MG3692B Microwave Signal Generator with Phase Pulse Modulation
Pre-Owned 20 GHz Anritsu MG3692B Microwave Signal Generator with Phase Pulse Modulation
Pre-Owned 20 GHz Anritsu MG3692B Microwave Signal Generator with Phase Pulse Modulation
Pre-Owned 20 GHz Anritsu MG3692B Microwave Signal Generator with Phase Pulse Modulation
Pre-Owned 20 GHz Anritsu MG3692B Microwave Signal Generator with Phase Pulse Modulation
Pre-Owned 20 GHz Anritsu MG3692B Microwave Signal Generator with Phase Pulse Modulation
Specifications
Brand Name :
Anritsu
Model Number :
MG3692B
Certification :
CNAS
Place of Origin :
USA
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
in stock
Packaging Details :
Carton
Form Factor :
Benchtop
Frequency :
20 GHz
Modulation :
Phase Pulse
Type :
Analog Digital Microwave RF
Condition :
Pre-Owned
Functions :
Tested, in Full Working Conditions
Description
Used 20 GHz Anritsu MG3692B Microwave Signal Generator 85-264 Vac 250 VA
Product Overview

Used 20 GHz Anritsu MG3692B Signal Generator Synthesizers Sweepers with fresh calibration certificate

The MG3690B series represents the ideal microwave signal generator, offering exceptional frequency coverage, leveled output power, spectral purity, switching speed, modulation performance, compact size, upgradeability, reliability, and comprehensive service support. These configurable signal generators are suitable for diverse applications ranging from R&D to manufacturing and depot repair.

Anritsu provides complete solutions including proven reliability with a standard 3-year warranty, plus industry-leading pre- and post-sale support.

The Anritsu MG3690B series of broadband signal generators covers both RF and microwave frequencies from 0.1 Hz to 70 GHz. For millimeter-wave frequencies, the MG3690B's coverage can be extended up to 325 GHz or beyond using external multipliers. This makes the MG3690B series an ideal signal source for both RF and microwave requirements, fully configurable from simple to high-performance applications.

The Anritsu MG3692B specifically covers the frequency range of 2 GHz to 20 GHz.

Technical Specifications
Warm Up Time:
From Standby: 30 minutes
From Cold Start (0°C): 120 hours to achieve specified frequency stability with aging
Instruments disconnected from AC line power for more than 72 hours require 30 days to return to specified frequency stability with aging
Power: 85-264 Vac, 48-440 Hz, 250 VA maximum
Standby: With AC line power connected, unit is placed in standby when front panel power switch is released from the OPERATE position
Weight: 18 kg maximum
Dimensions: 133 H x 429 W x 450 D mm
Available Options
Option Code Description
03 Ultra Low Phase Noise, main band
04 RF Downconverter .01 to 2.2 GHz
06 Analog Sweep Capability
15A High Power
1A Rackmount with Slides
26A External Pulse Modulation
27 Internal LF and Pulse Generators
28A Full Modulation Suite
2A Step Attenuator
SM5815 100 MHz EXT REF Loop
Frequently Asked Questions
Can you ship orders to Canada or Australia?
Yes, we can. We send orders worldwide.
What delivery method do you use and what is the delivery time?
We can ship by EMS, DHL, FedEx, UPS, TNT with tracking number. Usual delivery time is 4-7 workdays.
What is your payment term?
100% T/T payment before shipment.
How can I ask any other questions?
You can contact us online or leave us messages below.
Product Images
Pre-Owned 20 GHz Anritsu MG3692B Microwave Signal Generator with Phase Pulse Modulation Pre-Owned 20 GHz Anritsu MG3692B Microwave Signal Generator with Phase Pulse Modulation Pre-Owned 20 GHz Anritsu MG3692B Microwave Signal Generator with Phase Pulse Modulation
