MRI RF Shielded Window with Double-Pane Insulating Glass and Brass Mesh Painted Black for Temperature Range -40°C to +85°C
MRI RF Shielded Window with Double-Pane Insulating Glass and Brass Mesh Painted Black for Temperature Range -40°C to +85°C
MRI RF Shielded Window with Double-Pane Insulating Glass and Brass Mesh Painted Black for Temperature Range -40°C to +85°C
MRI RF Shielded Window with Double-Pane Insulating Glass and Brass Mesh Painted Black for Temperature Range -40°C to +85°C
MRI RF Shielded Window with Double-Pane Insulating Glass and Brass Mesh Painted Black for Temperature Range -40°C to +85°C
MRI RF Shielded Window with Double-Pane Insulating Glass and Brass Mesh Painted Black for Temperature Range -40°C to +85°C
Specifications
Delivery Time :
7-14days
RF Attenuation :
100-110 dB across 10 MHz to 130 MHz
MOQ :
1set
Shape :
Square Shape
Place Of Origin :
China
Packaging Details :
Wooden Packing Or Customized
Supply Ability :
2000 Pcs Per Month
Inner Pane :
8mm insulating hollow glass
Brand Name :
Jovi
Certification :
ISO
Inside Mesh :
Brass Mesh Painted Black 36 Mesh Number
Price :
$1580~$4120/set
Operating Temperature :
-40°C To +85°C
Model Number :
1-cf-7
Payment Terms :
T/T
Outer Pane :
5mm tempered glass
Description
JOVVI Double-Pane Insulating MRI Window
Product Performance & Applications

The JOVVI Double-Pane Insulating MRI Window features a 5mm tempered glass outer pane and an 8mm insulating hollow glass inner pane, providing enhanced thermal and acoustic insulation while maintaining RF shielding performance. The double-pane construction reduces heat transfer between the control room and scanner room, contributing to stable environmental conditions for the MRI system.

The insulating glass construction also provides superior acoustic performance, reducing transmission of scanner noise to the control room. The 98.5% transparency ensures clear patient observation through the shielding mesh. The window achieves 100–110 dB RF attenuation across 10 MHz to 130 MHz, compatible with 1.5T and 3.0T MRI systems.

The double-pane design is particularly beneficial in facilities with extreme climate conditions, where the scanner room requires strict temperature control for stable MRI operation, or where operator comfort is a priority in the control room.

Factory Advantages

JOVVI's glass processing capabilities include the fabrication of double-pane insulating glass units optimized for MRI shielding applications. The glass is selected for optical clarity and compatibility with the shielding mesh. The factory's quality control includes inspection of insulating glass seals to ensure long-term performance.

The factory's experience with MRI window applications informs the selection of glass thickness and pane spacing for optimal thermal, acoustic, and shielding performance. JOVVI's engineering team can provide guidance on window installation to maintain insulating properties.
