The Bariatric Transport Non-Magnetic MRI Wheelchair is a dedicated transport chair (not self-propelled) designed for bariatric patients weighing up to 700 pounds. Unlike standard bariatric wheelchairs that have large rear wheels for self-propulsion, this transport model has four small casters (8 inches each) – two swivel casters at the front and two fixed-direction casters at the rear. This configuration provides exceptional stability and eliminates the need for the patient to self-propel, which is often impossible for bariatric patients due to limited upper body strength or mobility. The chair is pushed by an attendant using reinforced push handles that are 42 inches from the floor – higher than standard to accommodate taller attendants or to provide better leverage. The frame is constructed from titanium-reinforced polymer with a steel-reinforced (non-magnetic stainless steel) cross-brace. The seat is extra-wide (28 inches) and extra-deep (22 inches) to accommodate large body habitus.

This wheelchair is essential for MRI facilities that serve bariatric patients who cannot self-propel and require assistance for all transport. Bariatric patients often have limited mobility, and pushing a heavy patient in a standard wheelchair can cause back injuries to staff. This transport chair is designed to be pushed, not self-propelled, and the four-caster configuration rolls more easily than a standard wheelchair with large rear wheels. The chair is ideal for transporting bariatric patients from their hospital room or the waiting area to the MRI suite. The extra-wide seat accommodates patients who would not fit in a standard bariatric wheelchair (24 inches). For patients who cannot transfer to the MRI table, the chair can be positioned partially inside the bore (the chair's width is 28 inches, which is less than the 70-cm bore diameter of 27.5 inches – a tight fit but possible with careful positioning).

• Frame: titanium-reinforced polymer (PEEK matrix with titanium wire).
• Seat width: 28 inches.
• Seat depth: 22 inches.
• Backrest height: 20 inches, fixed angle of 10 degrees recline.
• Armrests: extra-wide (4 inches), padded, fixed (non-flip-back for maximum strength).
• Footrests: swing-away, reinforced with aluminum cross-bar, 14 inches wide.
• Casters: four 8-inch casters – two front swivel with locking brakes, two rear fixed-direction (non-swivel). All casters have dual ceramic bearings and conductive rubber treads.
• Caster load rating: 200 pounds each.
• Push handles: 42 inches from floor, reinforced with internal aluminum rod, rubberized grip.
• Brakes: push-to-lock on front casters only (rear casters have no brakes – they are fixed and the chair is stopped by locking the front casters).
• Weight capacity: 700 pounds.
• Weight of chair: 55 pounds.
• Foldable: yes – the heavy-duty cross-brace folds the chair to 14 inches wide, but the chair is heavy; two staff members are recommended for lifting the folded chair.
• Seat-to-floor height: 22 inches.
• Includes: a non-magnetic seatbelt extender (30 inches longer than standard). Also includes a set of four anti-tip bars (front and rear) that deploy automatically when the chair is unfolded.
• Warranty: Five-year warranty on frame; two-year warranty on casters.
