The Bariatric Reclining Non-Magnetic MRI Wheelchair combines the features of a bariatric chair (600-pound capacity, 24-inch seat) with a full reclining backrest (up to 45 degrees). The chair is constructed from titanium-reinforced polymer with a steel-reinforced (non-magnetic stainless steel) recline mechanism. The seat is extra-deep (20 inches) to accommodate larger patients, and the leg rests elevate simultaneously with the backrest to maintain a comfortable position. The chair includes a heavy-duty gas spring (dual springs) to support the additional weight during recline. The armrests are extra-wide (4 inches) and height-adjustable. The rear wheels are 26 inches – larger than standard – to provide stability and distribute weight.

This wheelchair is for bariatric patients who also have conditions that prevent them from sitting upright. This includes patients with severe heart failure who need to sit semi-recumbent to breathe comfortably, patients with severe back who cannot tolerate upright sitting, and patients with pressure ulcers who need to offload the sacrum. These patients often present for MRI of the heart, spine, or other structures. The chair allows them to be transported from their hospital bed to the MRI suite in a comfortable, safe position. For patients who cannot be transferred to the MRI table (e.g., those who are too large for the table or who cannot lie flat), the chair itself can be positioned partially inside the bore, and the patient can remain in the chair for the scan – the reclining function allows the patient to be positioned at the appropriate angle for the anatomy of interest.

Frame

titanium-reinforced polymer (PEEK matrix with titanium wire – titanium is non-magnetic).

Seat width

24 inches.

Seat depth

20 inches.

Backrest height

20 inches, recline range 0 to 45 degrees in 5-degree increments.

Recline mechanism

dual non-magnetic gas springs (nitrogen), each rated for 400 pounds.

Leg rests

elevating, with calf support and foot plate, coordinated with backrest recline.

Gas spring release

lever on back of chair, extended to accommodate larger hands.

Armrests

4 inches wide, flip-back, padded with high-density foam.

Rear wheels

26 inches, composite, solid rubber tire, load-rated 350 pounds per wheel.

Push rims

polymer with rubber coating.

Front casters

8 inches, swivel with dual ceramic bearings.

Brakes

push-to-lock on rear wheels, with extended levers.

Weight capacity

600 pounds.

Weight of chair

65 pounds (heavier due to reinforcement and dual gas springs).

Foldable

no – rigid frame.

Seat-to-floor height

22 inches.

Includes

a non-magnetic seatbelt extender (24 inches longer than standard).

Also includes

a set of four anti-tip bars (front and rear) for stability when reclined.

Warranty

Five-year warranty on frame and recline mechanism.
