Pediatric & Veterinary Applications

1. Quality – Special Requirements for Non‑Adult Patients

Pediatric and veterinary imaging present unique challenges that standard lead glass may not address.

Jovvi pediatric grade: Same lead glass as standard but with enhanced flatness (±0.05 mm over 300 mm) and certified bubble‑free central zone (100 mm diameter). Critical for spotting subtle patient color changes under sedation.

2. Application Scenarios

Scenario A: Pediatric CT Room

• Challenge: Children may need repeated scans if they move. Technologist must see small body parts clearly.

• Jovvi recommendation: 2.0 mm Pb (lower than adult CT due to lower kVp protocols), AR coating to reduce monitor glare.

• Result: 30% reduction in pediatric repeat scans (hospital case study, n=450 patients).

Scenario B: Veterinary Teaching Hospital (Mixed Species)

• Challenge: One room used for cats (50 kVp), dogs (80–100 kVp), and horses (portable X‑ray). Glass must work for all.

• Jovvi recommendation: 2.2 mm Pb (middle ground) + wide‑angle clarity for viewing animals on floor.

• Result: Single spec for all species; staff no longer need to move between rooms.

Scenario C: Exotic Animal Clinic (Reptiles, Birds, Small Mammals)

• Challenge: Extremely small anatomical details (fractured turtle shell, bird wing). Need highest resolution.

• Jovvi recommendation: 1.8 mm Pb (thin = better resolution), polished both sides to maximum clarity.

• Result: Radiologists report ability to see 0.5 mm bone fragments.

3. Production Assurance – Pediatric/Veterinary Certification

Jovvi offers a Pediatric & Veterinary Compliance Pack including:

• Low‑energy attenuation data (50, 70, 90 kVp) – not provided by standard X‑ray testing

• Central bubble‑free zone certificate (100 mm diameter)

• Flatness measurement report (laser interferometry)

• Optional: cartoon‑style "child‑friendly" frame decals (Jovvi can supply, not installed on glass)
