The Single-Channel Dose Calibrator is a specialized instrument optimized for a single task: measuring radiopharmaceutical activity in pre-filled syringes. Unlike general-purpose calibrators that must accommodate vials, capsules, pills, and syringes, this instrument is designed exclusively for syringes. The single-channel design simplifies operation, reduces cost, and achieves superior measurement accuracy for syringe geometries. The ionization chamber is shaped to accept standard 1 mL, 3 mL, 5 mL, and 10 mL syringes, with a depth that positions the syringe tip (where most radioactive solution resides) at the optimal measurement point. The instrument includes no unnecessary features, making it ideal for hot cells where syringe measurement is the primary activity.

The Single-Channel Dose Calibrator is designed for nuclear medicine departments that prepare most of their patient doses in syringes — the case for virtually all PET/CT centers, most SPECT/CT departments, and many therapy programs. Primary applications include measuring F-18 FDG doses for PET/CT, quantifying Tc-99m-labeled compounds (MDP, sestamibi, MAG3, etc.) for SPECT studies, verifying Ga-68 DOTATATE doses for neuroendocrine tumor imaging, and measuring Lu-177 doses for PRRT when administered by syringe. The instrument is equally valuable for quality control of syringe-filling procedures, verifying that automated dispensing systems deliver the correct activity, and measuring residual activity in empty syringes after patient administration.

The Single-Channel Dose Calibrator achieves syringe-specific accuracy of ±3% — better than the ±5% typical of general-purpose calibrators measuring syringes. This improved accuracy is achieved through three design features. First, the ionization chamber geometry is optimized for the syringe shape, with sensitivity concentrated at the tip where most radioactive solution accumulates. Second, the instrument uses syringe-specific calibration factors derived from actual measurements of standard syringes filled with each isotope, rather than generic factors based on vial geometries. Third, the sample positioning is repeatable: a mechanical stop ensures that each syringe is inserted to exactly the same depth, eliminating a common source of variability. The response time is under 3 seconds for typical patient doses (5–20 mCi), and the auto-ranging function covers activities from 0.1 mCi to 2 Ci. The display shows activity in mCi or MBq in large, easy-to-read digits, with an audible alert when measurement is complete. The instrument includes a built-in library of syringe calibration factors for all common medical isotopes: F-18, Ga-68, Tc-99m, I-123, I-131, Lu-177, and Y-90. For each isotope, the library includes factors for multiple syringe brands and sizes (1 mL, 3 mL, 5 mL, 10 mL), and users can add custom factors for specialized applications. The data logging system stores up to 500 syringe measurements with complete metadata, and the USB port supports export to laboratory information systems. An optional printer produces labels for patient charts. The single-channel design offers several practical advantages. The instrument is smaller than general-purpose calibrators, requiring less bench space outside the hot cell. It is simpler to operate, with fewer controls and less training required. It is typically less expensive, making it attractive for departments with budget constraints. And because it is dedicated to a single application, there is no risk of using the wrong geometry setting — a common source of error with general-purpose instruments. For high-volume PET centers that measure hundreds of syringes each week, the Single-Channel Dose Calibrator offers the optimal combination of accuracy, simplicity, and value. By eliminating features not needed for syringe measurement, the instrument focuses on doing one thing exceptionally well. Nuclear medicine departments that pair this syringe-dedicated calibrator with a separate vial-dedicated calibrator achieve better overall accuracy than using a single general-purpose instrument for both geometries.
