Microwave High Directivity Waveguide Directional Coupler Compact Structure
Microwave High Directivity Waveguide Directional Coupler Compact Structure
Microwave High Directivity Waveguide Directional Coupler Compact Structure
Microwave High Directivity Waveguide Directional Coupler Compact Structure
Specifications
Brand Name :
Sinoscite
Model Number :
SNSD
Certification :
ISO 9001:2015
Place of Origin :
Sichuan, China
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
2000 Piece per month
Delivery Time :
Less than 4weeks
Packaging Details :
Standard exporting carton , each product individually wrapped, high density foam protection professional packing.
Operation frequency :
8.2~12.5GHz
VSWR :
<1.1
Degree of coupling :
-20±1.2dB
Directivity :
>25dB
Insertion loss :
<0.14dB
Dimensions(mm) :
63*63*53
Description

Microwave High Directivity High Capacity Compact Cross Waveguide Coupler

A directional coupler is a universal microwave / millimeter wave component that can be used for signal isolation, separation, and mixing, such as power monitoring, source output power stabilization, signal source isolation, and transmission and reflection sweep testing. The transmitted power is converted to the secondary line through various channels and interferes with each other and is transmitted in only one direction in the secondary line. Among a wide range of modern electronic systems.

We provide a range of Hot Sale new creative Waveguide cross directional coupler,and it can be customized according to your requirements.

1.Operation frequency:8.2~12.5GHz;
2.V.S.W.R:<1.1;
3.Degree of coupling:-20±1.2dB;
4.Directivity:>25dB
5.Insertion loss:<0.14dB
6.Dimensions(mm):63*63*53

Microwave High Directivity Waveguide Directional Coupler Compact Structure
