Hi-Rel High Density SMA/SMP/N RF 5 Position Integrated Connector For Cable
Hi-Rel High Density SMA/SMP/N RF 5 Position Integrated Connector For Cable
Hi-Rel High Density SMA/SMP/N RF 5 Position Integrated Connector For Cable
Hi-Rel High Density SMA/SMP/N RF 5 Position Integrated Connector For Cable
Hi-Rel High Density SMA/SMP/N RF 5 Position Integrated Connector For Cable
Hi-Rel High Density SMA/SMP/N RF 5 Position Integrated Connector For Cable
Specifications
Brand Name :
ELT
Model Number :
ELT-J28P-T5GJ~J28P-Z5GK
Certification :
CE ROHS
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10,000pcs Per Month
Delivery Time :
Within 3 weeks
Packaging Details :
Standard Export Carton
Product :
Integrated Connector
RF leakage :
Low
Certificate :
CE ROHS
Material :
Zinc Alloy / Brass/Metal
VSWR :
≤1.3
Application :
Aerospace、Defense 、high speed cable and constricted space
Pins :
5
Recommanded Cable :
CXN3506
Description

Salt-spray Resistance/Moisture-resistance RF Integrated Connector

Integrated connectors are miniaturized, lightweight connectors designed to achieve simultaneous transmission of multichannel signals. They are applicable to multi-signal transmission occasions where the space is limited, so the weight and environment characteristics of connectors are critical.

Our integrated connectors can be classified into RF integrated connectors and high & low frequency hybrid integrated connectors. Our integrated connectors are push-on screw-threaded coupling with metal outer conductor. Interfaces of our RF integrated connectors comply with GJB5246; Interfaces of our hybrid integrated connectors can be customized.

Integrated connectors are designed with compact size, keying for incorrect connections, reliable contact, shock resistance, anti-vibration, salt-spray resistance, high performance at high frequency, etc.

Specification
Frequency Range 0.04GHz-40Ghz
High Frequency 5 pins
VSWR ≤1.3
Cable Type CXN3506
Voltage Resistance 500V
Insulation Resistance ≥5000MΩ
Custom Size Available
Cable Flexible Cable

Product List

J23SM Series
J44P Series
J41B Series
J45P Series
J51M Series
J63M Series
J76P Series

Detailed Drawing
Hi-Rel High Density SMA/SMP/N RF 5 Position Integrated Connector For Cable

Hi-Rel High Density SMA/SMP/N RF 5 Position Integrated Connector For CableHi-Rel High Density SMA/SMP/N RF 5 Position Integrated Connector For Cable
