Dupont SFP-2660 IntegraFlux™ UF Module The Ultimate Solution for Thermal Power Plant Water Treatment
Dupont SFP-2660 IntegraFlux™ UF Module The Ultimate Solution for Thermal Power Plant Water Treatment
Dupont SFP-2660 IntegraFlux™ UF Module The Ultimate Solution for Thermal Power Plant Water Treatment
Dupont SFP-2660 IntegraFlux™ UF Module The Ultimate Solution for Thermal Power Plant Water Treatment
Specifications
Brand Name :
Dupont
Model Number :
SFP-2660
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
60000 Units per Month
Delivery Time :
5- 8 work days
Packaging Details :
standard export packing
Membrane Area Of SFP-2660: :
33m²
Nominal Pore Diameter Of SFP-2660: :
0.03 µm
Module Membrane Operating Pressure Of SFP-2660: :
0.35MPa
SFP-2660 Membrane Flow Range: :
1.3 – 4.0 M3/hr
Filtration Accuracy Of SFP-2660: :
0.01-0.1µm
Filter Method: :
External Pressure
Temperature: :
1-40ºC
Membrane Particle Size (max.): :
300 µ
Membrane Max Backwash Pressure Of This Model: :
2.5 Bar
TSS (max.) Of This Model: :
100 Mg/L
Main Material Of This Model: :
PVDF
Advantages: :
High-Flux, Low-Fouling Powerhouse
Application: :
Pretreatment
Highlight: :
SFP-2660 IntegraFlux™ UF Module, UF Module for Wastewater Reuse, RO Pretreatment UF Module
Description
In the thermal power plant water treatment industry, ensuring high-quality water for critical processes is non-negotiable—and the Dupont SFP-2660 IntegraFlux™ UF Module stands out as a game-changing ultrafiltration (UF) solution. Engineered by Dupont (leveraging Dow’s legacy in water treatment technology), this high-performance UF module is designed to address the strict water purity demands of thermal power operations, delivering reliable, efficient, and cost-effective filtration.
The Dupont SFP-2660 IntegraFlux™ UF Module adopts advanced PVDF (polyvinylidene fluoride) hollow fiber membrane technology, paired with an external pressure (out-to-in) filtration mode. This 工艺 (process) excels at removing bacteria, viruses, colloids, suspended solids, and other impurities that threaten thermal power systems—such as those in boiler feedwater pretreatment or cooling water recycling. Its 0.03μm nominal pore diameter ensures exceptional filtration accuracy (0.01-0.1μm), producing filtrate with turbidity ≤0.1 NTU and SDI ≤2.5, which meets the rigorous standards for protecting downstream equipment like RO systems and boiler components.
For thermal power plants, the Dupont SFP-2660 IntegraFlux™ UF Module serves three core 用途 (uses): 1) Pretreatment for boiler feedwater, removing contaminants to prevent scale and corrosion in boilers; 2) RO/NF pretreatment for desalination of brackish water (a common water source for power plants); 3) Wastewater reuse (e.g., recycling cooling tower blowdown), reducing freshwater consumption and environmental impact.

Key Specifications of Dupont SFP-2660 IntegraFlux™ UF Module

Parameter SI Units US Units
Membrane Area 33 m² 355 ft²
Filtration Flow Range 1.3 – 4.0 m³/hr 5.9 – 17.3 gpm
Max Operating Pressure 6.25 bar 93.75 psi
Max Backwash Pressure 2.5 bar 36 psi
Temperature Range 1–40°C 34–104°F
Operating pH 2–11 2–11
Max TSS Tolerance 100 mg/L 100 mg/L
Membrane Material Hydrophilic PVDF Hydrophilic PVDF
The Dupont SFP-2660 IntegraFlux™ UF Module offers unmatched advantages for thermal power plants: Its high-flux design (40-120 l/m²/hr at 25°C) boosts water production efficiency, while low-fouling PVDF membranes minimize cleaning frequency and energy use. The compact 6-inch diameter, 60-inch length (1860mm total length) saves valuable on-site space—critical for retrofits or new power plant layouts. Additionally, it tolerates up to 2,000 ppm NaOCl for robust cleaning, ensuring long-term performance and a prolonged membrane lifespan. For thermal power plants seeking to optimize water treatment, reduce operational costs, and meet sustainability goals, the Dupont SFP-2660 IntegraFlux™ UF Module is the trusted, certified (CE, NSF/ANSI 61) choice.
