MK-3 EDI Stack – Chemical-Free Regeneration for Industrial Ultrapure Water (1.6–4.5 m³/h)
MK-3 EDI Stack – Chemical-Free Regeneration for Industrial Ultrapure Water (1.6–4.5 m³/h)
MK-3 EDI Stack – Chemical-Free Regeneration for Industrial Ultrapure Water (1.6–4.5 m³/h)
MK-3 EDI Stack – Chemical-Free Regeneration for Industrial Ultrapure Water (1.6–4.5 m³/h)
MK-3 EDI Stack – Chemical-Free Regeneration for Industrial Ultrapure Water (1.6–4.5 m³/h)
MK-3 EDI Stack – Chemical-Free Regeneration for Industrial Ultrapure Water (1.6–4.5 m³/h)
MK-3 EDI Stack – Chemical-Free Regeneration for Industrial Ultrapure Water (1.6–4.5 m³/h)
MK-3 EDI Stack – Chemical-Free Regeneration for Industrial Ultrapure Water (1.6–4.5 m³/h)
Specifications
MK-3 Stack Minimum Water Production (M3 /Hr) :
1.6
Highlight :
Veolia E-Cell MK-3 EDI stack , medium-scale ultrapure water production , Suez EDI stack with warranty
MOQ :
1 Set
Delivery Time :
7 work days
Membrane Material: :
Hydrophilic PVDF (XP™)
Certification :
ISO 14001， CE ，ISO 9001
Voltage :
0–400 VDC
Model Number :
MK-3
MK-3 Stack Hardness (Ppm As CaCO3 ) :
<1.0
Price :
Negotiable
Module Application :
Industrial High Purity Water Preparation
Supply Ability :
200 Units per Month
Name :
MK-3
Brand Name :
VEOLIA
Sodium :
≤ 3 Ppb
Payment Terms :
T/T,Western Union,Paypal etc.
MK-3 Stack Maximum Water Production (M3 /Hr) :
4.5
Place of Origin :
China
Packaging Details :
Standard Export Wood Crate/Carton or Naked wrapped by film
Description
MK-3 Medium-Capacity EDI Purification Stack – Industrial Ultrapure Water Solution (1.6–4.5 m³/h)
Reliable Electrodeionization Solution for Industrial Ultrapure Water Production

The MK-3 Medium-Capacity Electrodeionization (EDI) Stack is designed for industrial facilities requiring stable and continuous production of high-purity water within a medium-flow range.

With an operating capacity of approximately 1.6 - 4.5 m³/h, the module provides an efficient solution for ultrapure water preparation while eliminating the need for conventional chemical regeneration. By combining ion exchange technology with electrically driven ion separation, the system continuously removes dissolved impurities and maintains consistent product water quality.

The compact structure of the MK-3 makes it suitable for both new installations and system upgrades where reliable performance and limited installation space are important considerations. The module is widely used in industries including semiconductor manufacturing, pharmaceutical water systems, power generation, and industrial process water treatment.

Key Advantages
Medium-Flow Industrial Performance
  • Designed for applications requiring moderate ultrapure water production
  • Operating capacity range: 1.6 - 4.5 m³/h
  • Balanced combination of efficiency, reliability, and compact design
Chemical-Free Regeneration
  • Uses electrical regeneration technology instead of acid and alkali chemicals
  • Reduces chemical storage and handling requirements
  • Provides a more sustainable purification process
Consistent High-Purity Water Quality
  • Produces mixed-bed quality ultrapure water
  • Product resistivity: ≥ 16 MΩ·cm
  • Sodium concentration: ≤ 3 ppb
  • Stable performance for sensitive industrial processes
Compact Modular Design
  • Space-saving configuration: 30 * 61 * 54 cm
  • Easy integration into existing treatment systems
  • Suitable for equipment upgrades and replacement projects
Technical Specifications
Parameter Specification
Product Model MK-3
Technology Electrodeionization (EDI)
Maximum Production Capacity 4.5 m³/h
Minimum Production Capacity 1.6 m³/h
Nominal Flow Rate 3.4 m³/h
Flow Range 1.7-4.5 m³/h
Recovery Rate Up to 96%
Dimensions (W * H * D) 30 * 61 * 54 cm
Shipping Weight Approx. 100 kg
Operating Voltage 0-300 VDC
Operating Current 0-5.2 ADC
Maximum Inlet Pressure ≤6.9 bar
Operating pH Range 4-11
Water Quality Performance
Parameter Performance
Product Water Resistivity ≥16 MΩ·cm
Sodium Concentration ≤3 ppb
Sodium Removal Efficiency ≥99.9%
Silica Concentration ≤5 ppb
Silica Removal Efficiency Up to 99%
Boron Concentration ≤0.08 ppb
Boron Removal Efficiency Up to 96%
Hardness Requirement <1.0 ppm as CaCO₃
Color ≤5 APHA
Core Technology

The MK-3 utilizes advanced electrodeionization technology by combining:

  • Ion exchange resin media
  • Selective ion membranes
  • Direct current electrical separation

This process enables continuous ion removal and automatic resin regeneration through water electrolysis, eliminating traditional chemical regeneration requirements.

Product Benefits
Feature Benefit
Chemical-Free Operation Lower environmental impact and operating cost
High Recovery Performance Improved water utilization efficiency
Compact Dimensions Easy installation in limited spaces
Stable Purity Output Suitable for critical industrial processes
Modular Configuration Flexible integration into water treatment systems
Typical Applications
  • Semiconductor chip cleaning and microelectronics manufacturing
  • Industrial boiler feed water systems
  • Power generation facilities
  • Pharmaceutical and biotechnology water treatment
  • Laboratory ultrapure water preparation
  • Industrial process water purification
Quality & Reliability

The MK-3 series is designed for industrial-grade operation with emphasis on:

  • Long-term operational stability
  • High-purity water consistency
  • Simplified system maintenance
  • Compatibility with advanced water treatment systems
Efficient Solution for Medium-Scale Ultrapure Water Production

The MK-3 provides a reliable and sustainable ultrapure water solution for industries requiring continuous high-quality water production. Its compact design, high recovery performance, and chemical-free operation make it an effective choice for modern industrial purification systems.
