MK-9 High-Capacity Chemical-Free Regeneration EDI Module with 97% Recovery Rate for Ultrapure Water Production
MK-9 High-Capacity Chemical-Free Regeneration EDI Module with 97% Recovery Rate for Ultrapure Water Production
MK-9 High-Capacity Chemical-Free Regeneration EDI Module with 97% Recovery Rate for Ultrapure Water Production
MK-9 High-Capacity Chemical-Free Regeneration EDI Module with 97% Recovery Rate for Ultrapure Water Production
MK-9 High-Capacity Chemical-Free Regeneration EDI Module with 97% Recovery Rate for Ultrapure Water Production
MK-9 High-Capacity Chemical-Free Regeneration EDI Module with 97% Recovery Rate for Ultrapure Water Production
MK-9 High-Capacity Chemical-Free Regeneration EDI Module with 97% Recovery Rate for Ultrapure Water Production
MK-9 High-Capacity Chemical-Free Regeneration EDI Module with 97% Recovery Rate for Ultrapure Water Production
Specifications
Silica (Ppm As SiO2 ) :
<1.0
MOQ :
1 Set
Delivery Time :
7 work days
Total Exchangeable Anions (Ppm As CaCO3 ) Of MK-9 Stack :
<13
Certification :
ISO 14001， CE ，ISO 9001
MK-9 Stack Dimensions (Cm As Width X Height X Depth): :
30 X 61 X 74
Model Number :
MK-9
Supply Ability :
200 Units per Month
Name :
MK-9
Brand Name :
VEOLIA
Typical New-Build Applications :
Solar Photovoltaics And Green Hydrogen
Payment Terms :
T/T,Western Union,Paypal etc.
Recovery :
Up To 97%
Price :
Negotiable
Voltage :
0–400 VDC
Place of Origin :
China
Packaging Details :
Standard Export Wood Crate/Carton or Naked wrapped by film
Description
MK-9 High-Capacity EDI Module for Industrial Ultrapure Water Production

The MK-9 High-Capacity Electrodeionization (EDI) Module is engineered for large-scale industrial ultrapure water applications requiring continuous, stable, and chemical-free purification performance.

With a high flow capacity of 6.0-10.0 m³/h, the MK-9 provides a reliable alternative to conventional ion exchange polishing systems by continuously removing dissolved ions without chemical regeneration. The advanced EDI technology combines ion exchange resins, ion-selective membranes, and electrical regeneration to maintain consistent high-purity water quality.

Engineered for demanding industrial environments, the module delivers ultrapure water with resistivity exceeding 16 MΩ·cm, making it suitable for critical applications including power generation, semiconductor manufacturing, pharmaceutical water systems, and advanced industrial processes.

Key Advantages
  • High-Capacity Continuous Operation: Designed for large-volume ultrapure water production with typical capacity of 6.0-10.0 m³/h
  • Chemical-Free Regeneration: Eliminates acid and caustic chemical requirements, reducing storage and handling needs
  • Consistent Ultrapure Water Quality: Produces mixed-bed quality water with resistivity >16 MΩ·cm
  • High Recovery & Efficient Design: Recovery rate up to 97% with no brine injection required
  • Reliable Industrial Construction: Leak-resistant structure designed for demanding operating conditions
Technical Specifications
Module ModelMK-9
TechnologyElectrodeionization (EDI)
Typical Water Production6.0-10.0 m³/h
Flow Rate8.0 m³/h (Typical Design)
Recovery RateUp to 97%
Product Water Quality>16 MΩ·cm Resistivity
Operating Voltage0-400 VDC
Dimensions (W * H * D)30 * 61 * 74 cm
Shipping WeightApprox. 165 kg
Inlet Pressure6.9 bar (100 psi)
Maximum Operating Temperature40°C
Pressure Drop2.4-3.4 bar
pH Operating Range4-11
Temperature Range4.4-40°C
Hardness Requirement<1.0 ppm as CaCO₃
Silica Requirement<1.0 ppm as SiO₂
Conductivity<22 μS/cm
Main Applications
  • Semiconductor and microelectronics manufacturing
  • Power plant boiler feed water systems
  • Pharmaceutical and biotechnology water treatment
  • Solar photovoltaic manufacturing
  • Green hydrogen production facilities
  • Laboratory ultrapure water systems
  • General industrial process water purification
Product Benefits
High Flow CapacitySupports large-scale ultrapure water demand
No Chemical RegenerationLower operating complexity and environmental impact
Continuous OperationStable water quality production
High Recovery RateImproved water utilization efficiency
Compact Module DesignEasy integration into treatment systems
Low MaintenanceReduced operational requirements
Advanced Solution for Large-Scale Ultrapure Water Production

The MK-9 provides an efficient, reliable, and environmentally responsible solution for industries requiring continuous high-purity water. Its advanced EDI technology delivers stable ultrapure water quality while reducing chemical consumption and simplifying system operation.
