Specifications
Brand Name :
Fenigal/OEM
Model Number :
IX-3A-5
Certification :
CE/NSF etc.
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, Western Union, Paypal etc.
Supply Ability :
200 set per month
Delivery Time :
15~30 days
Packaging Details :
Standard Export Wood Crate/Carton or Naked wrapped by film/Containerized
Technology :
Pressurized filtration
Material :
carbon steel/FRP/stainless steel
Design :
Skid mount/containerized
Water temp. :
5~35˚C
Water flow rate :
up to 200 m3/day.vessel
Voltage :
380V,415V,220V,can be customized
Application :
Surface, underground water, sewage water treatment
Size :
Dia.20cm~180cm
Control :
electronic,Manual/PLC
Description

Ion exchange electro-deionization EDI water purification system for Power Generation, Pharmaceutical, Semiconductor 1GP~7GPM

EDI-Series Electrodeionization Systems are a superior option to conventional mixed-bed deionization. Ultrapure water is processed by taking reverse osmosis permeate water and feeding it into the EDI System which uses electricity to continuously drive ions through deionization resins and ion selective membranes, thus producing a small concentrate stream.

These EDI systems do not require regeneration and there are no chemicals used for operation. EDI-Series Electrodeionization Systems are available in four flow ranges up to 7 gallons per minute (GPM). These systems feature a modular design, so they can be easily expanded to accommodate various requirements. Additionally, systems can be arranged in parallel for increased capacities.

Models EDI – 001 EDI – 003 EDI – 005 EDI – 007
Design
Nominal Capacity (gpm / lpm) 1 / 3.8 3 / 11.3 5 / 18.9 7 / 26.5
Operating Pressure
Nominal – Maximum (psi / bar)		 40 – 75 / 3 – 5 40 – 75 / 3 – 5 40 – 75 / 3 – 5 40 – 75 / 3 – 5
Nominal Discharge
Concentrate + Electrode (gpm / lpm)		 0.10 / 0.38 0.3 / 1.14 0.5 / 1.9 0.7 / 2.65
Nominal Recovery % 90 90 90 90
Feed Water Specifications
Feed Conductivity 1 Optimum FCE <9µS/cm Max FCE 33µS/cm
Total CO2 + HCO3 < 5 mgn CO2 + HCO3· (Optimum < 2 mg/l CO2 + HCO3)
Hardness < 1.0 ppm @ 90% recovery (ask about higher hardness)
Organics < 0.5 ppm TOC
Metals < 10 ppb
Feed Temp Optimum: 15° C – 30° C Range: (5° C – 35° C)
Feed pH Optimum: 7.0 – 7.5 Range: 5.0 – 9.5
Feed Chlorine ND
Silica, SiO2 < 0.5 ppm
System Component Specifications
Pressure Gauge At Filter Outlet: Stainless Steel Case, Bronze Internals. Glycerin–filled
Pressure Regulator Nickel Plated Bronze 3/4”. Set at 40 psi (2.7 bar)
Piping 3/4” PVC, Schedule 80
Valves Inlet Isolation Ball Valve, 2 Sample Valves
Flow Control Product, Concentrate & Electrode Flow Control Orifices
Switches Off/On Switch, Feed Low Pressure Cut–out, Concentrate Low Flow Cut–out
Filters 5 Micron Prefilter, 4.5” x 10”
Concentrate 1/2” QC
Feed / Product 3/4” FNPT
Product Quality 2 MΩ Dl Quality Indicator with Red – Green Indicator & Alarm
Typical Product Quality: 5 – 18.2 MΩ *Depends on FCE1 of RO Permeate
System Electrical
Power Usage – Nominal 200W 300W 400W 600W
Power Usage – Maximum .8kW 1.5kW 1.6kW 1.5kW
Electrical Input 178 – 264 VAC, 50/60Hz, 1 – Phase, FLA 20A
Systems Dimensions
Approximate Dimensions* L x W x H (in / cm) 25.75 x 25.75 x 60 /
65.41 x 65.41 x 152.40		 25.75 x 25.75 x 60 /
65.41 x 65.41 x 152.40		 25.75 x 25.75 x 60 /
65.41 x 65.41 x 152.40		 25.75 x 25.75 x 60 /
65.41 x 65.41 x 152.40
Approximate Weight (lbs / kg) 125 / 56 137 / 62 145 / 66 161 / 73
