8KW Energy-saving three-phase low-voltage hybrid inverter
8KW Energy-saving three-phase low-voltage hybrid inverter
8KW Energy-saving three-phase low-voltage hybrid inverter
8KW Energy-saving three-phase low-voltage hybrid inverter
8KW Energy-saving three-phase low-voltage hybrid inverter
8KW Energy-saving three-phase low-voltage hybrid inverter
8KW Energy-saving three-phase low-voltage hybrid inverter
8KW Energy-saving three-phase low-voltage hybrid inverter
8KW Energy-saving three-phase low-voltage hybrid inverter
8KW Energy-saving three-phase low-voltage hybrid inverter
Specifications
Brand Name :
RESUN
Model Number :
R-8K-TL
Certification :
IEC62109-1, IEC62109-2,EN61000-6-1, EN61000-6-3, FCC 15 class B,Rohs
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10000
Delivery Time :
3-30days
Model :
R-8K-TL
Power Rating :
8.0 KW
Max Efficiency :
97.5%
Operating Temperature Range :
-25~60℃
Battery Compatibility :
Lead-acid / Li-ion / User-defined
Rated Battery Voltage :
48V
Cooling Method :
Forced air cooling
Input Voltage Range :
50/60Hz
PV INPUT DC voltage, current :
200-650Vdc,22A+22A
Communication Interface :
RS485 / CAN / USB / Dry contact，Wi-Fi / GPRS
Certifications :
IEC62109-1, IEC62109-2,EN61000-6-1, EN61000-6-3, FCC15 classB, RoHS
Warranty :
5 years
Description

8KW Energy-saving three-phase low-voltage hybrid inverter

• Driven by advanced technology, reducing losses and saving electricity costs. ​
• Specially designed for three-phase low-voltage systems, with stable output. ​
• Automatically switch between grid connected and off grid modes to ensure continuous and stable power supply.


KEY STRENGTHS

Description

MODEL
R-8K-TL
Can Be Set
INVERTER OUTPUT
Rated Output Power 8,000W
Max.Peak Power 16,000WA
Rated Output Voltage
230/400Vac , Three-phase
 √
Load Capacity of Motors 5HP
Output Frequency
 50/60Hz
Number of Parallel 1-6units
AC OUTPUT(Grid
Rated Output Power
 8,000W
Max. Apparent Power
 8,000WA
Rated AC output phase current 11.6Aac
Rated Output Voltage 230/400Va
THDI <3%
Power Factor
0.8 leading to 0.8 lagging
Frequency 50/60HZ
BATTERY
Battery Type
Lead-acid / Li-ion / User Defined
 √
Rated Battery Voltage
 48V
Battery Voltage Range 40-60Vdc
Max. Generator Charging Current
 100A
Max. Grid Charging Current
 100A
Max.Hybrid Charging Current
 180A √
PV INPUT
Num. of MPPT Trackers
 2
Max.PV Array Power 6,000W+6,000W
Max. Input Current 22A+22A
Max.PV Isc
 37A+37A
Max.Voltage of Open Circuit 800Vdc+800Vdc
MPPT Voltage Range 200-650Vdc
MAINS/GENERATOR INPUT
Input Voltage Range
Phase voltage 170~280Vac,line voltage 305~485Vac
 √
Frequency Range 50/60HZ
Bypass Overload Current 23.2A
EFFICIENCY
MPPT Tracking Efficiency
 99.9%
Max. Efficiency
 97.5%
European Efficiency
 97.2%
GENERAL
Dimensions
700*440*260mm
Weight 39.2KG
Protection Degree IP65
Operating Temperature Range
-25~60℃,>45℃ derated
Humidity range
0～100%
Cooling Method
Forced air cooling
COMMUNICATION
Embedded Interfaces
RS485/CAN/USB/Dry contact
 √
External Modules(Optional)
Wi-Fi / GPRS
 √
CERTIFICATION
Safety
IEC62109-1, IEC62109-2
EMC
EN61000-6-1, EN61000-6-3, FCC 15 class B
Rohs Yes
