0Ω 2512 Chip Fixed Resistor 2W ±5% Ellon High Precision SMD RoHS Compliant
0Ω 2512 Chip Fixed Resistor 2W ±5% Ellon High Precision SMD RoHS Compliant
0Ω 2512 Chip Fixed Resistor 2W ±5% Ellon High Precision SMD RoHS Compliant
0Ω 2512 Chip Fixed Resistor 2W ±5% Ellon High Precision SMD RoHS Compliant
0Ω 2512 Chip Fixed Resistor 2W ±5% Ellon High Precision SMD RoHS Compliant
0Ω 2512 Chip Fixed Resistor 2W ±5% Ellon High Precision SMD RoHS Compliant
Specifications
Temperature Coefficient :
±100ppm/°C to ±600ppm/°C
Delivery Time :
5-8 work days
Resistance Value :
0Ω
Tolerance :
±5%
Supply Ability :
Large volume available
Packaging Details :
Tape and reel
Place of Origin :
Made in China
Certification :
RoHS / REACH
Power Rating :
2W
MOQ :
4000
Price :
Negotiable
Operating Temperature :
-55°C to +170°C
Package Size :
2512 (6.4mm × 3.2mm)
Brand Name :
Ellon
Payment Terms :
T/T
Model Number :
EHP25JS0R00VDJ
Description
0Ω 2512 Chip Fixed Resistor 2W ±5%
EHP25JS0R00VDJ 2512 0R 2W High Power Thick Film Chip Resistor with AEC-Q200 Certification. This 2512 chip resistor from Ellon delivers 0Ω resistance with ±5% tolerance and 2W rated power, giving designers a compact surface-mount part that keeps performance steady under load and temperature.
Technical Specifications
Tolerance±5%
Temperature Coefficient±100ppm/°C to ±600ppm/°C
Resistance Value0Ω
Operating Temperature-55°C to +170°C
Package Size2512 (6.4mm × 3.2mm)
Power Rating2W
Model NumberEHP25JS0R00VDJ
Key Features
  • Stable 2W rated power handling for demanding circuits
  • ±5% tolerance for dependable measurement accuracy
  • Low ±100ppm/°C to ±600ppm/°C temperature coefficient that keeps values stable as the board heats up
  • Compact 2512 SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
This chip resistor suits current sensing, power supplies, industrial control and consumer electronics. Its ceramic construction and stable electrical behaviour help designers meet tight tolerances in current sensing, power conversion and protection circuits, while the 2512 body keeps the layout compact.
Why Choose This Part
Buying directly from the manufacturer keeps the series available at competitive pricing with short lead times. Every batch is electrically tested before packing, so the resistance and tolerance you specify are the values you receive.
Packaging & Quality Assurance
Supplied on tape and reel for automatic pick-and-place assembly, in standard reel quantities for SMT lines. Every shipment is RoHS and REACH compliant and can be accompanied by a certificate of compliance on request. Contact us for samples, datasheets and volume pricing tailored to your project.
0Ω 2512 Chip Fixed Resistor 2W ±5% Ellon High Precision SMD RoHS Compliant
Application reference: EHP25JS0R00VDJ 2512 0R 2W High Power Thick Film Chip Resistor
