160 Ohm 6.4mm×3.2mm Chip Resistor 2W ±5% Ever Ohms High Precision SMD RoHS Compliant
160 Ohm 6.4mm×3.2mm Chip Resistor 2W ±5% Ever Ohms High Precision SMD RoHS Compliant
160 Ohm 6.4mm×3.2mm Chip Resistor 2W ±5% Ever Ohms High Precision SMD RoHS Compliant
160 Ohm 6.4mm×3.2mm Chip Resistor 2W ±5% Ever Ohms High Precision SMD RoHS Compliant
160 Ohm 6.4mm×3.2mm Chip Resistor 2W ±5% Ever Ohms High Precision SMD RoHS Compliant
160 Ohm 6.4mm×3.2mm Chip Resistor 2W ±5% Ever Ohms High Precision SMD RoHS Compliant
Specifications
Place of Origin :
Made in China
Certification :
RoHS / REACH
Operating temperature :
-55℃ to +155℃
Brand Name :
Ever Ohms
Resistance value :
160 Ohm
Tolerance :
±5%
TCR :
±100ppm/℃
Model Number :
CRH2512J160RE04Z
Payment Terms :
T/T
Delivery Time :
5-8 work days
MOQ :
4000
Package size :
6.4mm×3.2mm
Packaging Details :
Tape and reel
Price :
Negotiable
Supply Ability :
Large volume available
Rated power :
2W
Description
160 Ohm 6.4mm×3.2mm Chip Resistor 2W ±5%
CRH2512J160RE04Z High-Power Thick Film Resistor with 2W Power Rating, ±100ppm/℃ TCR, and RoHS Compliance. This 6.4mm×3.2mm chip resistor from Ever Ohms delivers 160 Ohm resistance with ±5% tolerance and 2W rated power, providing designers with a compact surface-mount component that maintains stable performance under load and temperature variations.
Technical Specifications
Parameter Specification
Resistance value 160 Ohm
Package size 6.4mm × 3.2mm
Rated power 2W
Operating temperature -55℃ to +155℃
Tolerance ±5%
TCR ±100ppm/℃
Model Number CRH2512J160RE04Z
Key Features
  • Stable 2W rated power handling for demanding circuits
  • ±5% tolerance for dependable measurement accuracy
  • Low ±100ppm/℃ temperature coefficient that maintains value stability as the board heats up
  • Compact 6.4mm×3.2mm SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
This chip resistor is ideal for current sensing, power supplies, industrial control systems, and consumer electronics. Its ceramic construction and stable electrical behavior help designers meet tight tolerances in current sensing, power conversion, and protection circuits, while the 6.4mm×3.2mm body maintains compact layout requirements.
Why Choose This Part
Purchasing directly from the manufacturer ensures competitive pricing with short lead times. Every batch undergoes electrical testing before packaging, guaranteeing that the specified resistance and tolerance values are precisely delivered.
Packaging & Quality Assurance
Supplied on tape and reel for automatic pick-and-place assembly in standard reel quantities for SMT production lines. All shipments are RoHS and REACH compliant and can include certificates of compliance upon request. Contact us for samples, datasheets, and volume pricing tailored to your project requirements.
160 Ohm 6.4mm×3.2mm Chip Resistor 2W ±5% Ever Ohms High Precision SMD RoHS Compliant
Application reference: CRH2512J160RE04Z High-Power Thick Film Resistor with 2W Power Rating
