High Load Power 200Kw Load Bank 0.5 Grade Orange With Phase Voltage 400V
High Load Power 200Kw Load Bank 0.5 Grade Orange With Phase Voltage 400V
Specifications
Brand Name :
KAIXIANG
Model Number :
200KW
Certification :
ISO9001
Place of Origin :
HEBEI CHINA
MOQ :
ONE SET
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, D/P, T/T, Western Union, MoneyGram
Supply Ability :
20 SETS ONE MONTH
Delivery Time :
ONE MONTH AFTER GET DEPOSIT
Packaging Details :
WOODEN CASE
Rated Power :
200kw
Installed Capacity :
Resistive load: 200kW
Frequency :
50 / 60HZ
Rated Voltage :
400VAC 3 phase 4 wire 50hz
Load Tolerance (each step) :
±5%
Load Tolerance(overall) :
±3%
Control Power :
220VAC, 1 phase 50 Hz,
Insulation :
F
Description

High Load Power 200Kw Load Bank 0.5 Grade Orange With Phase Voltage 400V

Product Description

New Load Bank Technology: using the international advanced AC load bank technology, overcome the old water bank defects, such as bear bumpy, unable to use when go to sea, realize Mooring Trial and Sea Trail, and simulate the real working condition of generator running.

Technical Parameters

Rating Voltage/Frequency 200Kw at 400VAC, 3 phase 4 wire, 50 Hz,
Max Load Power Resistive load:200kW
Load Steps 1kW,2kW,2kW,5kW,10kW,20kW,20kW,50kW, 100kW,min load step: 1 kW
PF(Power Factor) 1
Load Accuracy (each step) ±5%
Load Accuracy (overall) 3%
Display Precision 0.5 grade
Control Power 220VAC, 1 phase 50 Hz,
Wire Connection

Load power supply input——busbar

Control power supply input——three pin socket
Insulation F
Way of Working Continuous Work
Cooling Fan forced cooling, horizontal inlet air and vertical outlet cooling
Casing Color Grey(RAL7035)
Dimensions 1450 mm*900mm*870mm(length*wide*high)
Weight About 750kgs
Temperature -10℃～+50℃
Relative Humidity ≤95%
Altitude ≤1500 meter
Contactor Schneider
Fuse DELIXI
Alloy Resistance (self-developed)


Product Advantage

Stable Running: with the latest generation control module as the core, a sharp rise in system response speed and anti-interference performance, avoid function failure in complex electrical environment, and ensure system running stably and reliably.

Application

KX Load Banks can be used to satisfy the requirements for emergency stand-by power systems. These requirements concern acceptance testing and periodic on-site testing and maintenance of emergency and stand-by power systems. The essence of the requirements is that emergency and stand-by power systems are to be tested under load.
