General purpose grades
(PC+ABS)-Blend; Vicat/B 120 temperature = 120 °C; improved flow compared with T65
Rheological properties
Eigenschaft | Prüfbedingung | Einheit | Norm | typischer Wert | |
C | Melt volume-flow rate | 260℃/5kg | cm³/10 min | ISO 1133 | 18 |
| Melt viscosity | 1000 s-1/ 260 °C | Pa.s | b.o. ISO 11443-A | 200 |
| Molding shrinkage, parallel | 150x105x3 mm/ 260 °C / MT 80 °C | % | b.o. ISO 2577 | 0.5-0.7 |
| Molding shrinkage, normal | 150x105x3 mm/ 260 °C / MT 80 °C | % | b.o. ISO 2577 | 0.5-0.7 |
Mechanische Eigenschaften (23 °C/50 % r. F.)
Eigenschaft | Prüfbedingung | Einheit | Norm | typischer Wert | |
C | Tensile modulus | 1 mm/min | MPa | ISO 527-1,-2 | 2350 |
C | Yield stress | 50 mm/min | MPa | ISO 527-1,-2 | 54 |
C | Yield strain | 50 mm/min | % | ISO 527-1,-2 | 4.4 |
| Stress at break | 50 mm/min | MPa | ISO 527-1,-2 | 47 |
| Stress at break | 50 mm/min | % | ISO 527-1,-2 | >50 |
| Flexural modulus | 2 mm/min | MPa | ISO 178 | 2350 |
| Flexural stress at 3.5 % strain | 2 mm/min | MPa | ISO 178 | 73 |
| Flexural strength | 2 mm/min | MPa | ISO 178 | 84 |
| Izod impact strength | 23°C | kJ/m² | ISO 180/U | N |
| Izod impact strength | -30 °C | kJ/m² | ISO 180/U | N |
| Izod notched impact strength | 23 °C | kJ/m² | ISO 180/A | 48 |
| Izod notched impact strength | -30 °C | kJ/m² | ISO 180/A | 35 |
C | Charpy notched impact strength | 23 °C | kJ/m² | ISO 179/1eA | 50 |
C | Charpy notched impact strength | -30 °C | kJ/m² | ISO 179/1eA | 36 |
