Covestro Bayblend Products and Grades
Covestro Bayblend Products and Grades
Specifications
Brand Name :
Covestro
Model Number :
Pushing boundaries with advanced polycarbonate specialties
MOQ :
25KG
Price :
*USD to be negotiated
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Packaging Details :
25Kgs/BAG
Description

Product Description

Bayblend® variants exhibit an exceptional balance of properties, most notably outstanding toughness – even under cold temperatures – along with considerable rigidity, remarkable dimensional stability, excellent creep resistance, low moisture absorption, notable heat resistance, and high flame retardancy.

Key Beneifits

Covestro Bayblend Products and Grades

►Tough: Experience high toughness even at low temperatures.
►Heat-resistant: Rely on dimensional stability up to 142°C.
►Flame-retardant: Discover a wide portfolio of excellent flame-retardant grades.
Characteristic features Processing and fabrication Main areas of application

Color
Opaque, available in many opaque colors
Heat resistance
Vicat VST/B 120: standard grades: 112–142 °C,FR grades 93 – 136 °C


Stiffness
Tensile modulus: 2,000–2,800 MPa, mineral filled grades: 3,300–4,900 MPa, glass fiber-reinforced grades: 4,800–10,000 MPa


Toughness
High impact and notched impact strength even at low temperatures

Dimensional accuracy
High, low shrinkage, minimal warping


Flame retardance
Flame retardant grades with flammability classifica-tion to UL 94 V-0 as from 0.75 mm


Electrical insulation
Good, specific volume resistivity: 1014 Ohm · m, specific surface re sistivity: 1016 Ohm

Processing the raw material

Injection molding, extrusion, extrusion blow molding

Secondary processing

Thermoforming, e.g. by bending and stamping; cold forming, e.g. by high-pressure molding

Machining

Sawing, drilling, turning, milling, planing, grinding, tap-ping and die-cutting

Jointing

Screwing, bonding, welding and riveting

Finishing

Painting, printing, metallizing and laser marking
  • Automotive
  • Instrument panels and ventilation nozzles, instrument panel supports with add-on components, post finish-ers, airbag covers, metallized trim and emblems, con-soles, door handles, rear spoilers
  • Data technology
  • Housings for computers, monitors, printers, photo-copiers, laptops, televisions, DVD players and mobile phones
  • Electrical engineering and electronics
  • Connectors, housings for switches and battery char-gers, cable ducts
  • Domestic, leisure, sports
  • Panels for dishwashers, washing machines, housings for kitchen appliances

Products List

Code Property Grade
Bayblend® T45 PG (ABS+PC)-blend; Vicat/B 120 temperature = 112 °C; for electroplating applications

Non-reinforced

general purpose grades
Bayblend® T50 XF (PC+ABS)-blend; Vicat/B 120 temperature = 112 °C; excellent flow; good low temperature impact strength
Bayblend® T65 AT (PC+ABS)-blend; Vicat/B 120 temperature = 121 °C; improved antistatic behavior
Bayblend® T65 HG (PC+ABS)-blend; Vicat/B 120 temperature = 120 °C; easy flowing; high gloss; brilliant colors
Bayblend® T65 PG (PC+ABS)-blend; Vicat/B 120 temperature = 120 °C; easy flowing; good heat resistance; for electroplating applications
Bayblend® T65 XF (PC+ABS)-blend; Vicat/B 120 temperature = 120 °C; improved flow compared with T65 Bayblend® T80 XG (PC+ABS)-blend; Vicat/B 120 temperature = 130 °C; excellent flow; optimized surface quality for metallization (steam treatment)
Bayblend® T65 HI (PC+ABS)-blend; Vicat/B 120 temperature = 120 °C; grade with improved low-temperature impact strength and chemical resistance for automotive parts; also suitable for extrusion/extrusion blow molding and electroplating applications
Bayblend® T85 HG (PC+ABS)-blend; Vicat/B 120 temperature = 130 °C; easy flowing; high gloss; brilliant colors

Non-reinforced

general purpose grades
Bayblend® T85 SG (PC+ABS)-blend; Vicat/B 120 temperature = 130 °C; very good flow; suitable for DirectCoating/DirectSkinning
Bayblend® T85 XF (PC+ABS)-blend; Vicat/B 120 temperature = 130 °C; improved flow compared with T85
Bayblend® T90 HT (PC+ABS)-blend; high heat resistance; Vicat/B 120 temperature = 135 °C; easy flowing; ball indentation temperature >= 125 °C; suitable as supporting material for energized parts
Bayblend® T90 XF (PC+ABS)-blend; Vicat/B 120 temperature = 132 °C; good balance of melt flow, impact strength and stress cracking resistance
Bayblend® T90 XG (PC+ABS)-blend; Vicat/B 120 temperature = 135 °C; easy flowing; optimized surface quality for metallization (steam treatment)
Bayblend® T88 GF-10 Rubber modified (PC+SAN)-blend; 10 % glass fiber reinforced; Vicat/B 120 temperature = 134 °C; optimized heat ageing- and UV-stability; very good flow; tensile modulus = 4,800 MPa; good heat resistance

Glass fiber reinforced general

purpose grades
Bayblend® T88 GF-20 Rubber modified (PC+SAN)-blend; 20 % glass fiber filled; Vicat/B 120 temperature = 130 °C; optimized heat ageing- and UV-stability; very good flow; tensile modulus = 7,200 MPa; good heat resistance
Bayblend® T88 GF-30 Rubber modified (PC+SAN)-blend; 31 % glass fiber filled; Vicat/B 120 temperature = 134 °C; optimized heat ageing- and UV-stability; very good flow; tensile modulus = 10,000 MPa; good heat resistance
Bayblend® T90 MF-20 Rubber modified (PC+SAN)-blend; 20 % mineral filled; Vicat/B 120 temperature = 130 °C; very good flow; reduced coefficient of thermal expansion; tensile modulus = 4,900 MPa; good heat resistance

Mineral filled general purpose

grades
Bayblend® T95 MF (PC+ABS)-blend; 9 % mineral filled; Vicat/B 120 temperature = 142 °C; very good heat resistance; reduced coefficient of thermal expansion; tensile modulus = 3,350 MPa

Mineral filled general purpose

grades
Bayblend® W85 HI (PC+ASA)-blend; Vicat/B 120 temperature = 132 °C; easy flowing; improved weather resistance; excellent low temperature ductility; good heat resistance

General purpose grades with

improved weatherability
Bayblend® W85 XF (PC+ASA)-blend; Vicat/B 120 temperature = 134 °C; improved weather resistance; excellent low temperature ductility; good heat resistance
Bayblend® M850 XF (PC+ABS)-blend; easy flowing; Vicat/B 120 temperature = 131 °C; meet certain requirements of ISO Standard 10993-1; for further information please contact plastics@covestro.com

General purpose grades

for medical application*
Bayblend® FR3000 (PC+ABS)-blend; flame retardant; easy flowing; Vicat/B 120 temperature = 97 °C; UL recognition 94 V-0 at 1.5 mm; glow wire test: 960 °C at 2.0 mm; no juicing; good light stability

Non-reinforced flame

retardant grades
Bayblend® FR3000 HI (PC+ABS)-blend; flame retardant; Vicat/B 120 temperature = 97 °C; compared to FR3000 improved chemical resistance and stress cracking behavior; UL recognition 94 V-0 at 1.5 mm
Bayblend® FR3005 HF (PC+ABS)-blend; flame retardant; very easy-flowing; Vicat/B 120 temperature = 96 °C; UL recognition 94 V-0 at 1.5 mm
Bayblend® FR3008 HR (PC+ABS)-blend; flame retardant; Vicat/B 120 temperature = 103 °C; improved chemical and very good hydrolysis resistance; HDT/A >= 85 °C; UL recognition 94 V-0 at 1.5 mm; glow wire test: 960 °C at 2.0 mm; good light stability
Bayblend® FR3010 (PC+ABS)-blend; flame retardant; Vicat/B 120 temperature = 110 °C; increased heat resistance; UL recognition 94 V-0 at 1.5 mm; glow wire temperature (GWFI): 960 °C at 2.0 mm; improved chemical resistance and stress cracking behavior; successor to FR2010
Bayblend® FR3010 HF (PC+ABS)-blend; flame retardant; easy flowing; Vicat/B 120 temperature = 108 °C; UL recognition 94 V-0 at 1.5 mm; glow wire temperature (GWFI): 960 °C at 2.0 mm; optimized processability; good light stability
Bayblend® FR3010 IF (PC+ABS)-blend; flame retardant; Vicat/B 120 temperature = 108 °C; increased heat resistance; UL recognition 94 5VB (1.5 mm); glow wire temperature (GWFI): 960 °C at 2.0 mm
Bayblend® FR3011 (PC+ABS)-blend; flame retardant; easy flowing; Vicat/B 120 temperature = 118 °C; good heat resistance; UL recognition 94 V-0 at 1.5 mm; glow wire temperature (GWFI): 960 °C at 2.0 mm; good light stability
Bayblend® FR3015 BBS910 (PC+ABS)-blend; flame retardant; UV stabilized for improved light stability; Vicat/B 120 = 118 °C; UL recognition 94 V-0 at 1.5 mm

Non-reinforced flame

retardant grades
Bayblend® FR3030 (PC+ABS)-blend; flame retardant; Vicat/B 120 tempe - rature = 115 °C; extrusion grade; good extrusion and vacuum-forming behavior; UL recognition 94 V-0 at 1.5 mm; halogen-free according to DIN VDE 0472,815; glow wire temperature (GWFI): 960 °C at 1.0 mm
Bayblend® FR3040 (PC+ABS)-blend; flame retardant; Vicat/B 120 tempera - ture = 108 °C; HDT/A >= 85 °C; for thin-wall applications; very good burning behavior in small wallthicknesses (UL recognition 94 V-0 at 0.75 mm and above and V-1 at 0.6 mm)
Bayblend® FR1514 (PC+ABS)-blend; flame retardant; high heat resistance; Vicat/B 120 temperature = 136 °C; ball indentation tem - perature >= 125 °C; UL recognition 94 V-0 at 1.5 mm; suitable as supporting material for energized parts
Bayblend® FR1514 BBS073 (PC+ABS)-blend; flame retardant; Vicat/B 120 tem - perature = 136 °C; improved chemical resistance and stress cracking behavior compared to KU2-1514; ball indentation temperature >= 125 °C; UL recognition 94 V-0 at 1.5 mm; suitable as supporting material for energized parts
Bayblend® FR3020 (PC+ABS)-blend; 5 % mineral filled; flame retardant; Vicat/B 120 temperature = 103 °C; HDT/A >= 85 °C; for thin-wall applications; very good UL recognition in small wall thicknesses (V-0 at 0.75 mm); low smoke density

Mineral-filled flame

retardant grades
Bayblend® FR3021 PC+ABS)-blend; 15 % mineral filled; flame retardant; Vicat/B 120 temperature = 98 °C; high stiffness; tensile modulus = 4,800 MPa; UL recognition 94 V-0 at 1.5 mm; glow wire temperature (GWFI): 960 °C at 2.0 mm
Bayblend® ET3032 FR Rubber modified PC blend; 10 % mineral filled; flame retardant; Vicat/B 120 temperature = 108 °C; extrusion grade; good extrusion and vacuum-forming behavior; UL 94 V-0 (0.75 mm) (Covestro internal test); glow wire temperature (GWFI): 960 °C at 2.0 mm
Bayblend® FR410 MT Rubber modified PC blend; 10 % mineral filled; flame retardant; Vicat/B 120 temperature = 108 °C; very good UL recognition in small wall thicknesses (V-0 at 0.75 mm); for railway interiors; due to the special formulation of this grade, the final parts may require coating;
Bayblend® FR411 MT Rubber modified PC blend; flame retardant; mineral filled; Vicat/B 120 temperature = 99 °C; extrusion grade; for European railway interiors requiring EN45545;
Bayblend® FR421 MT Rubber modified PC blend; mineral filled; flame retardant; Vicat/B 120 temperature = 134 °C; extrusion grade for aircraft interiors;
