1A1 180mm metal bond diamond wheel for technology ceramics grinding
1A1 180mm metal bond diamond wheel for technology ceramics grinding
1A1 180mm metal bond diamond wheel for technology ceramics grinding
1A1 180mm metal bond diamond wheel for technology ceramics grinding
1A1 180mm metal bond diamond wheel for technology ceramics grinding
1A1 180mm metal bond diamond wheel for technology ceramics grinding
1A1 180mm metal bond diamond wheel for technology ceramics grinding
1A1 180mm metal bond diamond wheel for technology ceramics grinding
Specifications
Brand Name :
Shine Abrasives
Model Number :
4V2 1A1 14A2 9A3
Certification :
ISO
Place of Origin :
China
MOQ :
2 pcs
Price :
FOB
Payment Terms :
L/C, T/T
Supply Ability :
1000 PCS in one week
Delivery Time :
5 work days
Packaging Details :
one in paperbox
Radius :
3mm
Viscosity :
Standrad,good,as required
Maximum Operating Speed :
6,000-12,000 RPM
Max Working Speed :
High
Application :
Grinding, Sharpening, Cutting of Hard Materials
Compatibility :
Suitable for CNC and Manual Grinding Machines
Wheel Hole Size :
20mm-127mm
Hs Code :
6804211000
Feature :
Durable
Max Operating Temperature :
High
Color :
Gray / Silver
Bondtype :
Metallic
Coolant Required :
Yes
Hole Diameter :
standard
Wheel Diameter :
4-20 inches
Description

1A1 180mm metal bond diamond wheel for technology ceramics grinding

Shine Abrasives 1A1 180 mm metal bond diamond wheel for rough grinding technology ceramics works by using a metal matrix (like copper or cobalt) to securely hold diamond grits, which then grind the hard ceramic material. The main advantages are exceptional durability and form-holding stability, resulting in a longer wheel life.

Type 1A1 Flat metal bond diamond grinding wheel
Concentration 50%,75%,125%,150%
Mesh

46#,60#,80#,100#,120#(coarse grinding);

120#,150#,180#,200#,240#(medium grinding);
280#,320#,400#,500#,600#(fine grinding);
800#,1000#,1200#,1500#,2000#,3000#(polishing)
Specification

D75-H10-T5-X10 D150-H19-X5-T5

D125-T10-X10-H20/31.75 D100-T10-X10-H20/31.75
D175-H127-X4-T5 D250-H40-X10-T3
D300-H127-X10-T40 D350-H127-T20-X10
D400-H127-T40-X10 D500-H203-X10-T32
Specification sizes can be customized
Application ard alloy,high alumina porcelain,optical glass agate gemstone, semiconductor material,ceramics,stone,etc

1. Long life Metal bond grinding wheels last longer than those made by other methods. This boosts productivity by cutting down on dressing frequency and wheel changes.
2. Intricate Designs Complex forms can be created, and since wear rates are low they last longer than in other types.
3. Heat quickly dissipates through the metal core. This property makes metal bond appropriate.
