Specifications
Brand Name :
Briture
Model Number :
End Type
Certification :
ISO
Place of Origin :
China
MOQ :
1000kg
Price :
USD 0.71-1.01/KG
Payment Terms :
L/C, T/T
Supply Ability :
60 MT per year
Delivery Time :
15-18days
Packaging Details :
20kgs or 1200kgs net each bag, 24MTS/1X20`FCL
Diameter (mm) :
0.75
Length (mm) :
0.35
L/D :
45
TS (MPa)±7.5% Type :
1100
Type :
Loose /Glued
Description

Steel Fiber Hooked End Type

Product Description

The end hook bonded steel fiber are prominent: good dispersion, tensile strength not less than 1000MPa, shape of the end hook is not easy to pull out, economy, and good water solubility of the bonded steel fiber.

Material properties: high quality and high speed wire.

The bonded steel fibers are widely used in factory floors, highways, bridges, airport runways, tunnels, pipelines, linings of infrastructure, ports and wharves, marine engineering, nuclear test bases, rocket launch bases and earthquake resistant buildings.

It can ensure that the fibers do not agglomerate and disperse evenly in concrete mixing, and can improve the impact resistance and fatigue resistance of concrete and the impermeability of concrete. Because of its high tensile strength, good toughness and low price, compared with other shapes of steel fibers, its tensile strength, compressive strength and flexural strength have been greatly improved, which is suitable for some key anti-seismic and anti riot structural projects. It has been widely used in roads, highway slope protection bridges, tunnels, airports, ports, railway sleepers and so on.

Specification:

Item Diameter (mm) Length (mm) L/D TS (MPa)±7.5% Type
80/60 0.75 60 80 1100, 1800 Glued
80/50 0.62 50 80 1200 Glued
65/60 0.9 60 65 1000, 1800 Glued
65/35 0.55 35 65 1200 Glued
4G 80/60 0.75 60 80 2100 Glued
5D 65/60 0.9 60 65 1800 Glued
1.0/50 1.0 50 50 1000, 1800 Loose
0.75/50 0.75 50 66 1100 Loose /Glued
1.0/60 1.0 60 60 1100, 1800 Loose /Glued
0.5/25 0.5 25 50 1200 Loose
0.6/30 0.6 30 50 1200 Loose
0.75/35 0.75 35 45 1100 Loose /Glued

Application

1. Highway Bridge

2. Hydraulic dam

3. Railway Engineering

4. Port and marine engineering

5. Tunnel and mine engineering

Construction suggestions

The steel fiber content can be 30-80kg / m3 for pavement construction and 50-100kg / kg / m3 for bridge construction

Steel fiber concrete mixing process: the construction is carried out according to the conventional construction, and no special adjustment is required

Packing

20kgs or 1200kgs net each bag, 24MTS/ 1X20`FCL
