Specifications
Model Number :
RO-P5
Brand Name :
LEDKING or OEM & ODM
Place of Origin :
Guangdong, China
MOQ :
1
Price :
$243-263
Pixel pitch :
5mm
Pixel density :
40000 dot/m2
Pixel configuration :
1R1G1B
Max power consumption :
25W
Panel weight :
0.25KG
Cabinet size :
960mm*960mm*90mm
Cabinet resolution :
192 dot * 192 dot
Quantity of panel :
36pcs
Hub connecting :
HUB75-E
Best viewing angle :
170/120
Screen power supply :
AC110V/220V - 5V60A
Max power capacity :
1350W/m2
Refresh frequency :
1920-3840 HZ/S
Brightness :
5000-5500 mcd/m2
Operating temperature :
-10C°~45C°
Description
Outdoor P5 LED Video Wall with IP65 Waterproof Die-Cast Aluminum Cabinet and 1920Hz-3840Hz Refresh Rate
Outdoor P5 LED Video Wall with IP65 Waterproof Die-Cast Aluminum Cabinet and 1920Hz-3840Hz Refresh Rate
Outdoor P5 LED Video Wall with IP65 Waterproof Die-Cast Aluminum Cabinet and 1920Hz-3840Hz Refresh Rate
Products Description
Item
Outdoor P4.81
Outdoor P5
Outdoor P5




Module





Panel Dimension
250mm(W) * 250mm(H)
160mm(W) * 160mm(H)
320mm(W) * 160mm(H)
Pixel pitch
4.81mm
5mm
5mm
Pixel Density
43264 dot/m2
40000 dot/m2
40000 dot/m2
Pixel configuration
1R1G1B
1R1G1B
1R1G1B
Specification
SMD2727/SMD1921
SMD2727
SMD1921
Pixel resolution
52 dot * 52 dot
64 dot * 32 dot
64 dot * 32 dot
Max power consumption
40W
25W
40W
Panel weight
0.65KG
0.25KG
0.45KG
Item
Outdoor P4.81
Outdoor P5
Outdoor P5








Cabinet
Cabinet size
500*1000mm*90mm, 500*500*90mm
960mm*960mm*90mm
960mm*960mm*90mm
Cabinet Resolution
104 dot * 208 dot, 104 dot * 104 dot
192 dot * 192 dot
192 dot * 192 dot
Quantity of panel
8pcs, 4pcs
36pcs
18pcs
Hub connecting
HUB75-E
HUB75-E
HUB75-E
Cabinet Material
Diecsting aluminum cabinet
Simple Iron/ waterproof iron cabinet
Diecsting aluminum cabinet
Maintenance Method
Front/Back service
Front/Back service
Front/Back service
Best viewing angle
170/ 120
170/ 120
170/ 120
Screen power supply
AC110V/220V - 5V60A
AC110V/220V - 5V60A
AC110V/220V - 5V60A
Max power capicity
1200 W/m2
1350W/m2
976W/m2
Average power
600 W/m2
675W/m2
488W/m2
Item
Outdoor P4.81
Outdoor P5
Outdoor P5







Technical
Signal Index
Driving IC
ICN 2037 / 2153
ICN 2037 / 2153
ICN 2037 / 2153
Scan Rate
1/ 13S
1/8S
1/8S
Refresh frepuency
1920-3840 HZ/S
1920-3840 HZ/S
1920-3840 HZ/S
Display color
4096*4096*4096
4096*4096*4096
4096*4096*4096
Brightness
3800-4000cd/m2
5000-5500 mcd/m2
5000-5500 mcd/m2
Life span
100000Hours
100000Hours
100000Hours
Control distance
< 100M
< 100M
< 100M
Best viewing distance
4-40M
5-40M
5-40M
Operating temperature
- 10C°~45C°
- 10C°~45C°
- 10C°~45C°
Operating Humidity
10-90 %
10-90 %
10-90 %
IP protective index
IP65
IP65
IP65
>> Most in Kinglight and 3840 refresh rate, if need to change detail,
and More Pixel Pitch and techinal details, feel free to contact us <<
