| Module Specifications | |
|---|---|
| Module Size | 320mm(W)*160mm(H) |
| Pixel Pitch | 1.86 mm |
| Pixel Density | 359856 dot/㎡ |
| Pixel Configuration | 1R1G1B |
| LED Specification | SMD1515 |
| Pixel Resolution | 172 dot*86 dot |
| Max Power Consumption | 30W |
| Panel Weight | 0.3KG |
| Cabinet Specifications | |
|---|---|
| Cabinet Size | 640mm*480mm |
| Cabinet Resolution | 344 dot * 258 dot |
| Quantity of Panel | 6pcs |
| Hub Connecting | HUB75-E |
| Material | Die-casting aluminum cabinet |
| Maintenance Method | Front/Back service |
| Best Viewing Angle | 170/120° |
| Power Supply | AC110V/220V-5V40A |
| Max Power Consumption | 976W/㎡ |
| Average power consumption | 488W/m² |
| Technical Signal Index | |
|---|---|
| Driving IC | ICN1065 |
| Scan Rate | 1/43S |
| Refresh Frequency | 3840-7680HZ/S |
| Display Color | 4096*4096*4096(16bit) |
| Contrast Ratio | 4000:1 |
| Brightness | 600-800 cd/㎡ |
| Life Span | 100000Hours |
| Best Viewing Distance | 1-30M |
| Operating Temperature | -10℃~60℃ |
| Operating Humidity | 10-70% |
| IP Protective Index | IP43 |
Command and Control Centers: Used in locations requiring 24/7 uninterrupted operation and high-density information visualization, such as public security, traffic police, emergency response, power, energy, and military sectors. They can clearly and seamlessly display critical information such as GIS maps, surveillance videos, and large data screens.
Broadcast and Television Studios: Serving as a large background screen for news broadcasts, variety shows, and weather forecasts, offering true-to-life, uniform colors without the moiré patterns and water ripples often seen in camera photography, effectively enhancing the visual effects and sophistication of program production.
High-End Conference and Auditoriums: Replaces traditional projectors in corporate boardrooms, large auditoriums, and remote video conferencing rooms. Supports high-definition video playback and seamless display of PPTs, documents, and data charts, improving meeting efficiency and viewing experience.
Commercial Display and Brand Spaces: Applied to corporate showrooms, brand flagship stores, high-end retail stores, museums, science and technology museums, etc. Used to showcase corporate image, product promotion, and interactive experiences, attracting audiences with its stunning visual impact.
