C29 MAX 48V 18Ah Electric Mountain Bike 960W Fat Tire With 29 Wheels Hydraulic Disc Brakes
C29 MAX 48V 18Ah Electric Mountain Bike 960W Fat Tire With 29 Wheels Hydraulic Disc Brakes
C29 MAX 48V 18Ah Electric Mountain Bike 960W Fat Tire With 29 Wheels Hydraulic Disc Brakes
C29 MAX 48V 18Ah Electric Mountain Bike 960W Fat Tire With 29 Wheels Hydraulic Disc Brakes
C29 MAX 48V 18Ah Electric Mountain Bike 960W Fat Tire With 29 Wheels Hydraulic Disc Brakes
C29 MAX 48V 18Ah Electric Mountain Bike 960W Fat Tire With 29 Wheels Hydraulic Disc Brakes
C29 MAX 48V 18Ah Electric Mountain Bike 960W Fat Tire With 29 Wheels Hydraulic Disc Brakes
C29 MAX 48V 18Ah Electric Mountain Bike 960W Fat Tire With 29 Wheels Hydraulic Disc Brakes
C29 MAX 48V 18Ah Electric Mountain Bike 960W Fat Tire With 29 Wheels Hydraulic Disc Brakes
C29 MAX 48V 18Ah Electric Mountain Bike 960W Fat Tire With 29 Wheels Hydraulic Disc Brakes
Specifications
Battery Charger :
54.6V 2A charger
Top Speed :
40 km/h (International) ; 25 km/h (EU)
Certification :
CE certified
Pedal :
Aluminium alloy pedals
Front Brake :
ZOOM dual-piston hydraulic disc brake, 160 mm rotor
Model Number :
C29 Max-BK
Brand :
Reliago
Crank :
Aluminum alloy crank, 170 mm
Rear Brake :
ZOOM dual-piston hydraulic disc brake, 160 mm rotor
Ingress Protection Rating :
IPX4
Packaging Details :
Single item195*124*19 cm,34.45kg
Display :
S869 2.4" 3-button multi-function HD LCD display
Max Climbing Angle :
30°
Rear Wheel :
Kenda 29" x 2.1" tyre with reflective stripes, 30 TPI
Max Load Capacity :
150 kg
Delivery Time :
To be negotiated
Battery :
48V 18Ah battery
Frame :
Aluminium alloy frame
Front Wheel :
Kenda 29" x 2.1" tyre with reflective stripes, 30 TPI
Rear Rack :
Steel rear rack, max load 25 kg
Operating Temperature :
-10℃ to 40℃
Supply Ability :
Minor customization, Drawing-based, customization, Sample-based customization, Full customization
Torque :
65 Nm
Max Range :
Up to 120 km in assist mode
Handlebar :
Aluminum alloy handlebar, 68 cm
Mudguard :
Full-coverage steel mudguards
Pedal Assist System :
Speed sensor
Brand Name :
Reliago
Product Name :
C29MAX Electric Bike
Headlight :
40 LUX headlight, manually operated
Transmission System :
Shimano Tourney 1×7-speed derailleur system
Recommended Rider Height :
Suitable for riders from 170 cm to 200 cm
Place of Origin :
Guangdong, China
Bike Weight :
29.25kg
Fork :
Single-crown aluminium suspension fork, 100 mm travel, non-adjustable, with lockout
Product Size :
184*113*68 cm
Payment Terms :
T/T,Western Union
Motor :
48V 960W (International ) ; 48V 250W (EU)
Taillight :
Integrated brake taillight
Charging Time :
8–9 hours
Pedal Assist Level :
0-5 levels
Description

Reliago C29 MAX 48V 18Ah Electric Mountain Bike – 960W Fat Tire E-Bike with 29" Wheels & Hydraulic Disc Brakes

Product Overview

The Reliago C29 MAX Electric Mountain Bike is a high-performance off-road e-bike designed for riders who want power, range, and comfort. Equipped with a powerful 48V motor system, 18Ah long-range battery, and 29-inch Kenda mountain tires, the C29 MAX delivers excellent performance for commuting, trail riding, and outdoor adventures.
With a torque sensor, Shimano 7-speed drivetrain, hydraulic disc brakes, and suspension fork, this electric mountain bike provides smooth control and confidence on different terrains.

Product Specifications

Specification Item Detailed Parameters Specification Item Detailed Parameters
Product Name C29MAX Electric Bike Brand Reliago
Model Number C29 Max-BK Motor 48V 960W (International ) ; 48V 250W (EU)
Torque 65 Nm Battery 48V 18Ah battery
Display S869 2.4" 3-button multi-function HD LCD display Battery Charger 54.6V 2A charger
Max Range Up to 120 km in assist mode Charging Time 8–9 hours
Top Speed 40 km/h (International) ; 25 km/h (EU) Max Climbing Angle 30°
Frame Aluminium alloy frame Front Wheel Kenda 29" x 2.1" tyre with reflective stripes, 30 TPI
Handlebar Aluminum alloy handlebar, 68 cm Rear Wheel Kenda 29" x 2.1" tyre with reflective stripes, 30 TPI
Crank Aluminum alloy crank, 170 mm Headlight 40 LUX headlight, manually operated
Transmission System Shimano Tourney 1×7-speed derailleur system Taillight Integrated brake taillight
Fork Single-crown aluminium suspension fork, 100 mm travel, non-adjustable, with lockout Pedal Aluminium alloy pedals
Front Brake ZOOM dual-piston hydraulic disc brake, 160 mm rotor Mudguard Full-coverage steel mudguards
Rear Brake ZOOM dual-piston hydraulic disc brake, 160 mm rotor Rear Rack Steel rear rack, max load 25 kg
Bike Weight 29.25kg Recommended Rider Height Suitable for riders from 170 cm to 200 cm
Certification CE certified Max Load Capacity 150 kg
Product Size 184*113*68 cm Ingress Protection Rating IPX4
Pedal Assist System Torque sensor Operating Temperature -10℃ to 40℃
Pedal Assist Level 0-5 levels

Core Product Features

The large-capacity lithium battery provides up to 120 km assisted riding range, making it suitable for long-distance commuting and adventure riding.
Powerful 48V Motor System:960W international version motor ; 250W EU compliant version ; 65 Nm torque
The torque sensor provides natural riding assistance by detecting rider input, creating a smoother cycling experience.
Shimano 7-Speed Gear System
Hydraulic Disc Brake System

Application Scenarios

Urban Commuting
Mountain & Trail Riding
Outdoor Adventure
Fitness & Recreation

Frequently Asked Questions (FAQ)

Q1: What is the maximum range of C29 MAX?
The C29 MAX can reach up to 120 km in pedal assist mode, depending on rider weight, speed, terrain, weather, and assistance level.

Q2: What is the maximum speed?
Speed depends on regional regulations : International Version: up to 40 km/h ; EU Version: 25 km/h

Q3: Is this e-bike suitable for mountain riding?
Yes. With:29-inch tires ; Suspension fork ; Hydraulic brakes ; High torque motor
It is suitable for trails and off-road riding.

Q4: How long does battery charging take?
The charging time is approximately:8–9 hours ; with the included 54.6V 2A charger.

Q5: What rider height is suitable?
Recommended rider height:170 cm – 200 cm
