Industrial-grade DL185 Evaporator for Large Commercial Cold Storage
Industrial-grade DL185 Evaporator for Large Commercial Cold Storage
Industrial-grade DL185 Evaporator for Large Commercial Cold Storage
Industrial-grade DL185 Evaporator for Large Commercial Cold Storage
Industrial-grade DL185 Evaporator for Large Commercial Cold Storage
Industrial-grade DL185 Evaporator for Large Commercial Cold Storage
Specifications
MOQ :
1
Application :
Cold Room,Freezer
Matched Area :
185㎡
Rated Voltage :
380V
Delivery Time :
1 Month
Model :
DL-37.9/185
Model Number :
DL-37.9/185
MOQ :
1 Sets
Place of Origin :
China
Payment Terms :
T/T,Western Union
Packing :
Woodcase packing
Price :
Discussed
Supply Ability :
100PC
Packaging Details :
WOODEN CASE
Nominal Refrigeration Capacity :
37.9 kW (37900 W)
Brand Name :
Ruifujie
Warranty :
1 year
Description
Industrial-grade DL185 Evaporator for Large Commercial Cold Storage
Industrial-grade DL185 Evaporator for Large Commercial Cold Storage
Product Images
Industrial-grade DL185 Evaporator for Large Commercial Cold Storage Industrial-grade DL185 Evaporator for Large Commercial Cold Storage Industrial-grade DL185 Evaporator for Large Commercial Cold Storage
Product Advantages
  • Heavy-Duty Cooling Power: 37.9kW nominal cooling capacity, perfectly matched for 185㎡ large cold rooms, maintaining ultra-stable low temperature under heavy commercial loads.
  • Full-Coverage Air Distribution: 24000 m³/H massive airflow with 15m throw range, eliminating temperature stratification and cooling dead zones in spacious cold storage.
  • Quadruple Fan Reliability: 4×414W 380V fans with 500mm diameter, engineered for 24/7 continuous industrial operation with consistent performance.
  • High-Efficiency Defrost System: 7200W fin defrost + 2400W drain pan defrost, efficiently clears heavy frost buildup in high-humidity cold environments.
  • Optimized Refrigerant Circuit: 22.7L tube volume with φ25/φ48mm inlet/outlet tubes, enhancing heat exchange efficiency for demanding low-temperature applications.
Technical Specifications
Parameter Specification
Model DL-37.9/185 (DL185)
Nominal Refrigeration Capacity 37.9 kW (37,900 W)
Applicable Cold Room Area 185 ㎡
Tube Volume 22.7 L
Refrigerant Inlet/Outlet Diameter φ25 / φ48 mm
Fan Configuration 4 units
Fan Diameter 500 mm
Fan Voltage 380 V
Total Fan Power 1,656 W (4 × 414 W)
Air Volume 24,000 m³/H
Air Throw Range 15 m
Fin Defrost Power 7,200 W
Drain Pan Defrost Power 2,400 W
Company Profile
With more than 20 years of experience, Shenzhen Ruifujie is a large modern refrigeration enterprise specializing in refrigeration compressors. We produce scroll, piston, rotor, semi-hermetic and screw compressors, exported to countries like Pakistan, Turkey, Canada and Russia. We provide professional OEM/ODM services, have strong technical strength in refrigeration, and win global customers' praise for high-quality compressors and good services.
Industrial-grade DL185 Evaporator for Large Commercial Cold Storage Industrial-grade DL185 Evaporator for Large Commercial Cold Storage Industrial-grade DL185 Evaporator for Large Commercial Cold Storage Industrial-grade DL185 Evaporator for Large Commercial Cold Storage Industrial-grade DL185 Evaporator for Large Commercial Cold Storage Industrial-grade DL185 Evaporator for Large Commercial Cold Storage
Packaging and Shipping
Supply Ability 1000000 pieces/year, MOQ is usually one piece
Shipping Time Sample order in stock within 3 days, Bulk order generally 10-15 working days after receiving deposit
Shipping Method Support by sea, by air, by express (DHL, FedEx, UPS...)
Payment Terms TT/Western Union
30% Advance Payment, 70% Final Payment
Shipping Port Ningbo Port, Shanghai Port, Shenzhen Port
Industrial-grade DL185 Evaporator for Large Commercial Cold Storage
Frequently Asked Questions
Q: What is your MOQ?
A: If we have the products in stock, it will be no MOQ. If we need to produce, we can discuss the MOQ according to customer's exact situation.
Q: What are the main products?
A: Semi-hermetic compressor, Hermetic Compressor, Condenser Unit, Air Cooler, Spare Parts, Chillers and Evaporators.
Q: What is your delivery time?
A: The time of delivery is 3-10 working days after payment.
Q: What about the services and aftersale?
A: Guarantee quality, the warranty period is 1 Year.
Q: What are your price terms?
A: We offer EXW or FOB Shenzhen pricing.
