PP Honeycomb Dry Van Bodies , Dry Freight Truck Bodies 1T-10T Load Capacity
PP Honeycomb Dry Van Bodies , Dry Freight Truck Bodies 1T-10T Load Capacity
PP Honeycomb Dry Van Bodies , Dry Freight Truck Bodies 1T-10T Load Capacity
PP Honeycomb Dry Van Bodies , Dry Freight Truck Bodies 1T-10T Load Capacity
PP Honeycomb Dry Van Bodies , Dry Freight Truck Bodies 1T-10T Load Capacity
PP Honeycomb Dry Van Bodies , Dry Freight Truck Bodies 1T-10T Load Capacity
PP Honeycomb Dry Van Bodies , Dry Freight Truck Bodies 1T-10T Load Capacity
PP Honeycomb Dry Van Bodies , Dry Freight Truck Bodies 1T-10T Load Capacity
PP Honeycomb Dry Van Bodies , Dry Freight Truck Bodies 1T-10T Load Capacity
PP Honeycomb Dry Van Bodies , Dry Freight Truck Bodies 1T-10T Load Capacity
Specifications
Model NO. :
Dry Truck Body
Seats :
≤5
Horsepower :
150-250hp
Engine Capacity :
4-6L
Heat Preservation Type :
Foam Material
Tire Certification :
ISO
Tire Design :
Radial
Condition :
New
Colour :
White or Other Colour
Transport Package :
CKD
Specification :
as per request
Trademark :
SNOWFALL
Origin :
China
HS Code :
8707901000
Supply Ability :
200 sets per month
Transmission Type :
Cargo Van
Emission Standard :
Euro 5
Power :
Diesel
Load Capacity :
1-10t
Drive Wheel :
4×2
Shape :
Single Bridge
Customization :
Available | Customized Request
Place of Origin :
China
Brand Name :
SNOWFALL
Certification :
ISO , SGS, CE
MOQ :
1set
Price :
Negotiation
Packaging Details :
flat pack
Delivery Time :
10 days
Description
Dry truc body :
PP Honeycomb Dry Van Bodies , Dry Freight Truck Bodies 1T-10T Load Capacity
PP Honeycomb Dry Van Bodies , Dry Freight Truck Bodies 1T-10T Load Capacity
PP Honeycomb Dry Van Bodies , Dry Freight Truck Bodies 1T-10T Load Capacity
PP Honeycomb Dry Van Bodies , Dry Freight Truck Bodies 1T-10T Load Capacity
PP Honeycomb Dry Van Bodies , Dry Freight Truck Bodies 1T-10T Load Capacity
Material:
FRP with PP Homeycomb panel for roof, side wall, front, rear door.
The floor : Steel checkered plate
Door: Double rear door. Stainless steel door frame and locking.
We can load by CKD or assembled type.

Specification:
1. Glass reinforced fiber plastic + PP honeycomb cellcore + glass reinforced fiber plastic
Thickness of GFRP is from 1mm to 2.5mm.
2. Surface: Anti slip patten and diamond patten

Features:
1 light-weight,save energy and cost
2 high strength
3 water-proof and flame retarded
4 excellent weather resistance,moisture or aging
5 shock absorption
6 easy to fabricate
7 sound insulation
8 colorful and decorative
9 environmental friendly
10 low Electrical & thermal conductivity
Standard Size (T)
Snowfall Dry Cargo Box
L (mm) 3160 4380 6250
W (mm) 1740 2000 2450
H (mm) 1650 1920 2300
Panel Type FRP + Honeycomb + FRP
Roof Panel 1.5mm + 18mm + 1.5mm
Front Panel 1.5mm + 18mm + 1.5mm
Wall Panel 1.5mm + 18mm +1.5mm
Floor Panel 3mm Steel Checked Plate
Rear Door 1 pair of 20mm thick FRP plywood swing doors
*Customize size available 2m ~ 9m (Please specify the details)
