Parameter | Details | |
---|---|---|
Type 1 | Type 2 | |
Spray Gun | Gravity Gun | Suction Gun |
Gun nozzle: 1.2mm, Gun pressure: 2.0-3.0 MPa | Gun nozzle: 1.5mm, Gun pressure: 2.0-3.0 Mpa | |
Substrate | Dry 1K primer surface with smooth effect | |
Paint Preparation | 1K Mud Yellowpaint- thinner-EX10/EX20/EX30 | |
Mix Ratio | 1 : 1 (base paint : thinner) | |
Spraying Layers | 2-3 coats | |
Flash Off Time | 3-5 mins , 20-25℃ | |
Surface Dry Time | 15-20mins | |
Time to Polish | 1h, P1000 sanded paper |
Relationship between drying temperature and time of 1K base coat | ||
---|---|---|
Temperature | Surface Drying time | Time to Polish |
25℃ | 10-15 mins | 1 hour |
35℃ | 5-10 mins | 40 mins |
60℃ | 3-5 mins | 15 mins |
To prevent irritation of the respiratory tract, skin, and eyes during application, it is advised to use the proper personal protection equipment.Only for professional usage.
The base may be mask and sprayed with additional varnish or clear coat after 15 minutes at 20 °C.
In order to ensure the quality and stable colors, our raw material are mainly purchased from BASF, MERCK, ECKART, EASTMAN, DSM, BYK and BAYER etc. Being the strategic partner of BASF, we are the best Chinese buyer of their raw materials.
