Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Specifications
Brand Name :
MOOGE
Model Number :
MT
Certification :
CE
Place of Origin :
Jiangsu, China
MOQ :
1
Price :
$160,000.00/sets 1-1 sets
Payment Terms :
L/C, T/T
Supply Ability :
30 Set/Sets per Month plastic pet bottle washing recycling line
Delivery Time :
90 working days
Packaging Details :
Standard export packaging or Customized packaging
Application :
PET Bottle Recycling
Condition :
New
Automatic Grade :
Automatic
Plastic Type :
PET
Production Capacity (kg/h) :
500 - 5000
Machine Type :
PET Bottle Washing Line
Equipment List :
Dewatering Machine, Floating Washing Tank, Hot Air Dryer, Frication Washer, Label Separator, Label Remover, Hot Washing Tank
Max.Production Capacity (kg/h) :
5000
Voltage :
Customized
Dimension(L*W*H) :
62m x 5m x4.5m
Power (kW) :
400
Weight (T) :
20
Warranty :
12 Months
Key Selling Points :
High Productivity
Video outgoing-inspection :
Provided
Applicable Industries :
waste plastic recycling machinery
Showroom Location :
Turkey, Italy, Viet Nam, Brazil, Mexico, Thailand, Argentina, Colombia, Ukraine
Machinery Test Report :
Not Available
Marketing Type :
Ordinary Product
Warranty of core components :
1 Year
Core Components :
PLC, Bearing, Gearbox, Motor, Gear
Color :
Customized
Motor brand :
Simens or customized
Speed Control :
Inverter control
Bearing brand :
HRB or customized
Material of washing part :
Stainless steel or Carbon steel
Man power :
6-10 person
Final flake size :
12-14mm
Steam use :
Optional
Heating way :
electricity, steam or source
Moisture content :
1%
After Warranty Service :
Video technical support, Online support
Local Service Location :
Egypt, Viet Nam, Philippines, Peru, Pakistan, India, Mexico, Thailand, Bangladesh, South Africa, Kyrgyzstan
Port :
Shanghai seaport
Description
Product Overview
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
This MT-series Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine is mainly used to recycling the waste PET bottles, water bottles, cola bottles, PET sheet and PET packing containers, etc. The Waste Plastic Recycling Plant Scrap Pet Bottle Recycle Washing Line can easily remove the labels, caps, rings, glue, dirties and other impurities off from the pet plastic, finally we will get ideal PET flakes with good quality for reuse.
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Product Specification
The Waste Plastic Recycling Plant Scrap Pet Bottle Recycle Washing Line we made with capacity from 500kg/h to 5000 kg/h.
We can design the machine layout into "L" or "U" shape according to buyer's actual factory area and requirements.
Model
Capacity
Installed Power
Steam Use
Water Supply
Manpower
Area Required
MT-500
500 kg/hr
190 KW
Optional
4-5 m3/hr
4-6 Person
60*5*5 m
MT-1000
1000 kg/hr
260 KW
Optional
5-7 m3/hr
8-10 Person
80*8*5 m
MT-2000
2000 kg/hr
400 KW
Suggest Use
10-15 m3/hr
10-12 Person
80*8*5 m
MT-3000
3000 kg/hr
600 KW
80,000 Kcal
20-30 m3/hr
12-16 Person
100*8*10 m
MT-4000
4000 kg/hr
800 KW
100,000 Kcal
30-40 m3/hr
15-20 Person
135*10*10 m
MT-5000
5000 kg/hr
1000 KW
120,000 Kcal
40-50 m3/hr
15-20 Person
135*10*10 m
We adopted well-known brand for the main motor, necessary parts of the machine.We manufacture the machine strictly according to the technical drawings and we can also make the components as buyer request
Item
Specification
Raw Material
Waste Rigid Plastic PET bottles, PET sheet, PET packages, etc
Finished Product
Clean dry plastic flakes (size can be recycled as buyer request)
Main Machine List
Bale Opener, Trommel, Label Remover Machine, Sorting Belt, Pre-washer Machine, Belt Conveyor, Crusher, Cold Washing Tank, High Speed Friction Washer, Hot Washing Tank, Centrifugal Dryer, Zig-zag Air Classifier, Color Sorter, Packing Silo
Machine Material
Machine frame is made by carbon steel, the machine washing part is made by SUS 304
Main Components
NSK/SKF bearing, TTO oil sealing, Guomao reducer,etc.
Electric Components
ABB/Delta inverter, Omron temperature meter, Schneider contactor, Chint switch, Siemens made in China motor, etc.
Warranty Period
One Year from the Machine Operation within 18 Months from the B/L Date
Turnkey After Service
Technical Support including the machine layout, electric diagram, working manual, engineer available to buyer's factory overseas for helping installation, commissioning, training workers, etc. consumable parts provided; 24-hours online after sale service;
Features At-A-Glance
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Bale Opener Machine
Function: Open the pressed PET bales
>With 4 roller cylinder feeding the bottles equally, claw steel is very strong with 20mm thickness.
>Machine chamber made by solid strong steel, chamber size 1.6*1.6m (depth x width).
>We can make it with forklift working platform to push the bales, or with a hopper for temporary store the bales.
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Label Remover Machine
Function:remove the labels from the bottles
>Blades made by tungsten carbide and are fixed by screw easy to adjust and replace
>The barrel designed with hydraulic system to lift up the chamber which is convenient to replace the blades
>The machine bottom with holes to drain out liquid which contained in the bottles, good for machine use
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Plastic Crusher Machine
Function: crushing the PET bottles to small flakes.
>With water inlet doing the wet grinding which can extend the blades lifespan, reduce the dust generation.
>Crusher upper hopper opened by screw motor which save manpower
>Bearing house is installed outside of the crusher chamber so no dirty goes inside for longer use.
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Floating Washing Tank
Function: with cold water washing out dirty from the flakes
>With the top rollers automatically take out the caps and rings and other impurities but with less water taken out
>Rotor shaft made by seamless steel tube.
>Screw is made by stainless steel, we have different model of floating washing tank according to your requirements.
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Hot Washing Tank
Function: with hot water washing to remove oil/glue and other dirty from the flakes.
>The tank made with insulation layer to keep the hot water temperature and save energy.
>Feeding caustic soda or chemical detergent to washing the bottle flakes for better effect
>The water is heated up by steam, steam is generated by the steam boiler
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Horizontal Dewatering Machine
Function: take out dirty and remover water from the bottle flakes
>With high raotary speed reach up to 1500rpm with better effect for removing the water
>With the famous SKF roller bearing fixed outside for long lifespan
>Inside with mesh layer made by SUS304, which is also cleaned by the water spray system
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
Customer Onsite
We sold the plastic recycling machine to hundreds of buyers from more than 100 countries in the world. Our high quality machine and good service are all well received by numerous customers from domestic and overseas. And we are expecting to seek the long-term business partner all over the world.
Waste Beverage Bottle Washing Drying Plastic Pet Recycling Machine
FAQ
  • What kind of machine do you want? Plastic washing line? Plastic pelletizing line? Shredder? Crusher? Or other machine?
  • What material do you want to recycling? PE film? PP woven bag? HDPE/PP bottle? PET bottle? or other plastic? Can you please send material photos for our reference?
  • What capacity (kg/h) do you want for the machine? We have 300kg/h, 500kg/h, 1000kg/h or larger…
  • What is the product final size (mm) do you want? Normally, plastic film/bags pieces is 30-50mm, plastic bottle flakes is 14mm, plastic pellet is 3mm…
  • Other special requirements such as the machine color, machine motor brand, layout design…
