Specifications
Model NO. :
MUR860
Luminous Intensity :
NO LIGHT
Color :
NO LIGHT
Structure :
GPP Chip
Material :
Silicon
Transport Package :
Tube
Specification :
High Power Package
Trademark :
JF, JH
Origin :
China
HS Code :
85411000
Supply Ability :
10000000000piece/Year
Package Size :
5.58cm * 1.48cm * 0.38cm
Package Gross Weight :
0.001kg
Place of Origin :
China
Certification :
ISO9001:2015, ISO14001:2015, IATF16949
MOQ :
3,000 Pieces
Price :
Negotiable
Delivery Time :
Peak Season Lead Time: one month Off Season Lead Time: within 15 workdays
Payment Terms :
LC, T/T, PayPal
Description
Product Description

SCHOTTKY BARRIER RECTIFIER DIODES
Electronics Component

Part Number: MUR820 THRU MUR8120

Major Parameter:

Type VRRM IF IR(25ºC) IR(100ºC) IR(125ºC) VF Trr Outline
V A μA uA uA V nS
MUR820 200 8.0 5.0 50 0.975 35 TO-220AC
MUR840 400 8.0 5.0 50 1.3 35
MUR860 600 8.0 5.0 50 1.7 35
MURS860 600 8.0 5.0 50 2.3 25
MUR880 800 8.0 5.0 50 2.4 45
MUR8120 1200 8.0 5.0 50 3.30 50
MURS8120 1200 8.0 5.0 50 3.30 50

Package: TO-220AC
Manufacturer: Jinan Jingheng Electronics Co., Ltd.

Features:

· Plastic package has Underwriters Laboratory Flammability Classification 94V-0

· Single rectifier construction
· High surge capability
· For use in low voltage ,high frequency inverters, free wheeling ,and polarity protection applications
· High temperature soldering guaranteed:2 0 C/10 seconds, 0.25"(6.35mm)from case
· Fast switching for high efficiency
· Low forward voltage drop
· Component in accordance to RoHS 2002 95 EC and WEEE 2002 96 EC

Application:
Used in power supply, lighting, auto, home appliance field
