Specifications
Brand Name :
Pinsheng
Application :
Home Appliances, Solar Energy Storage Systems
Model Number :
PE-ESS-03
Weight :
CUSTOMIZED
Place of Origin :
HUNAN
Product name :
All in one battery
Battery type :
Lifepo4/lithium Battery
Cycle life :
6000 Cycles
Voltage :
96v/153.6v etc customized
Nominal Capacity :
50AH-300AH /Custom
Protection :
smart BMS
OEM/ODM :
Accepatable
Apllication :
Household Energy Storage
Features :
all in one ( built in inverter)
MOQ :
no
Warranty :
10 years
Anode Material :
LFP
Battery Size :
LifePO4
The charging ratio :
50A
The discharge rate :
100A-200A
Storage Type :
dry, cool and ventilation
MOQ :
2
Price :
CN¥6,892.94-7,144.86
Description
Product Description
Pinsheng All in One Stacked Modules 51.2V LiFePO4 Lithium Battery 10Kwh 20Kwh Energy Storage Battery and 10Kw Hybrid Inverter
Pinsheng All in One Stacked Modules 51.2V LiFePO4 Lithium Battery 10Kwh 20Kwh Energy Storage Battery and 10Kw Hybrid Inverter
Pinsheng All in One Stacked Modules 51.2V LiFePO4 Lithium Battery 10Kwh 20Kwh Energy Storage Battery and 10Kw Hybrid Inverter
Pinsheng All in One Stacked Modules 51.2V LiFePO4 Lithium Battery 10Kwh 20Kwh Energy Storage Battery and 10Kw Hybrid Inverter
Pinsheng All in One Stacked Modules 51.2V LiFePO4 Lithium Battery 10Kwh 20Kwh Energy Storage Battery and 10Kw Hybrid Inverter
Pinsheng All in One Stacked Modules 51.2V LiFePO4 Lithium Battery 10Kwh 20Kwh Energy Storage Battery and 10Kw Hybrid Inverter
Specification
Model
PE-NAIO-1010
PE-NAIO-1015
PE-NAIO-1020
PE-NAIO-1025
Battery Voltage
204.8V
153.6V
204.8V
256V
Output
Parameters
(AC)
Rated Power
10kW
Curren Ratedt
43.5A
Voltage/range
230V/176Vac~270Vac
Frequency Ranges
50/60Hz
Efficiency
0.99lagging~0.99leading(settable)
THDI
<2%
Battery
Battery voltage range
85v~400V
Battery pack rated voltage
204.8V
153.6V
204.8V
256V
Capacity Of Battery
5.12kWh*2
5.12kWh*3
5.12kWh*4
5.12kWh*5
Charge/discharge current
50A/50A
80A/80A
Battery type
LiFePO4(LFP)
DC input
Max. Input Power
13kW
Max. PV voltage
550V
MPPT range/nominal
125V~500V/360V
Max. input current
12A
MPPT tracker/strings
2/2
Eps output
Rated power w/va
10kW
Max. Output Power
12.5kW 60S/15kW 1S
Rated voltage
230V
Rated current
43.5A
Rated frequency
50/60Hz
Automatic switchover time
<20ms
THDU
<2%
Appearance
Size(W/D/H)
640mm*490mm*1262mm
640mm*490mm*1455.5mm
640mm*490mm*1649mm
640mm*490mm*1842.5mm
Weight(approx)
210kg
230kg
291kg
357kg
General
data
DC max. efficiency
98.2%
MPPT efficiency
99%
Operating temperature
-20°C~55°C
Protection level
IP21
Noise emission(typical)
<35dB
Display
LCD
Interface
CAN/RS485/WIFI
Pinsheng All in One Stacked Modules 51.2V LiFePO4 Lithium Battery 10Kwh 20Kwh Energy Storage Battery and 10Kw Hybrid Inverter
Hunan Pinsheng Energy Technology Co.,LTD located in Changsha City, Hunan Province, We focus on developing and producing Li-ion battery and battery system integration ,through many years development and research.we have formed a complete industry chain from research, production to sales. Our lithium ion battery has the characteristics of longer recycle life,more higher security and more reliability, higher energy density and other superior performance.products are widely used in electric bikes, E-scooter, electric motorcycles, electric tricycles, golf cart,fork lift,electric vehicles, UPS,telecommunication system,off grid wind &solar energy storage and etc .Pinsheng Energy Battery products sell well at home and abroad ,we has strict quality guarantee system to ensure high-quality products. We put customers' needs at the first and listen to their suggestions.We continuously improve our product quality and services. We have our own R&D team so customized products are fine for us,Pinsheng Energy has now became a competetive manufacturer in China, we are edicated to be a top OEM &ODM manufacturer in China .
Pinsheng All in One Stacked Modules 51.2V LiFePO4 Lithium Battery 10Kwh 20Kwh Energy Storage Battery and 10Kw Hybrid Inverter
Pinsheng All in One Stacked Modules 51.2V LiFePO4 Lithium Battery 10Kwh 20Kwh Energy Storage Battery and 10Kw Hybrid Inverter
Pinsheng All in One Stacked Modules 51.2V LiFePO4 Lithium Battery 10Kwh 20Kwh Energy Storage Battery and 10Kw Hybrid Inverter
Carton Package,Wooden Case. 2022 New Home Solar System Solution 5KWh 8.8KWh 10KWh 20KWh 22KWh 30KWh LiFePO4 Energy Storage System
Pinsheng All in One Stacked Modules 51.2V LiFePO4 Lithium Battery 10Kwh 20Kwh Energy Storage Battery and 10Kw Hybrid Inverter
Pinsheng All in One Stacked Modules 51.2V LiFePO4 Lithium Battery 10Kwh 20Kwh Energy Storage Battery and 10Kw Hybrid Inverter
