3.2V LFP Battery with 2000 Cycles and Prismatic Design for EV and Solar Systems
3.2V LFP Battery with 2000 Cycles and Prismatic Design for EV and Solar Systems
3.2V LFP Battery with 2000 Cycles and Prismatic Design for EV and Solar Systems
3.2V LFP Battery with 2000 Cycles and Prismatic Design for EV and Solar Systems
Specifications
Model Number :
LFP20Ah
Certification :
UN38.3, MSDS, IEC62133, RoHS
Place of Origin :
China
MOQ :
100pieces
Payment Terms :
T/T
Supply Ability :
10'000Pieces daily
Delivery Time :
within 10days
Packaging Details :
Bulk packing
Nominal Voltage :
3.2V
Description
MSDS Lithium Iron Phosphate LFP Battery 20AH 25AH 3.2V Prismatic Cell For EV

Lithium Iron Phosphate LFP battery 20AH 25AH 3.2V prismatic cell for EV and solar systems.

Specification Value
Nominal Voltage 3.2V
Nominal Capacity 20AH (other capacity 25AH/30AH/50AH/80AH/100AH/120AH/200AH/270AH/280AH)
Discharge cut-off 2.5V
Charge cut-off 3.65V
Charge current 20A
Discharge current 20A
Peak discharge current 60A
Impedance Resistance ≤ 5mΩ
Dimension 22*65*140mm
Weight 0.6KG
Discharge Temperature Range -4°F ~ 140°F (-20°C ~ 60°C)
Charge Temperature range 32°F ~ 113°F (0°C ~ 45°C)
Charge Method CC/CV
Cycle Life over 2000 times
Product Images
3.2V LFP Battery with 2000 Cycles and Prismatic Design for EV and Solar Systems 3.2V LFP Battery with 2000 Cycles and Prismatic Design for EV and Solar Systems
Product Advantages
3.2V LFP Battery with 2000 Cycles and Prismatic Design for EV and Solar Systems
Discharge Cycle Life
3.2V LFP Battery with 2000 Cycles and Prismatic Design for EV and Solar Systems
Other Hot Sale Lithium Iron Phosphate Cylindrical Battery Cells
Model No. Nominal Voltage Typical Capacity Size Charge Rate Discharge Rate Weight(g) Cycle life (80% DOD)
IFR10440 3.2V 200mAh 10.3*44.2 0.2-0.5C 0.2-3C 7 ≧2000
IFR14430 3.2V 400mAh 14.2*43 0.2-0.5C 0.2-3C 13 ≧2000
IFR14500 3.2V 600mAh 14.2*50.2 0.2-0.5C 0.2-3C 18 ≧2000
IFR16340 3.2V 400mAh 16.2*34.2 0.2-0.5C 0.2-3C 13 ≧2000
IFR18500 3.2V 1000mAh 18.1*50.2 0.2-0.5C 0.2-3C 34 ≧2000
IFR18650 3.2V 1500mAh 18.5*65.3 0.2-0.5C 0.2-3C 42 ≧2000
IFR18650 3.2V 1800mAh 18.5*65.3 0.2-0.5C 0.2-3C 62 ≧2000
IFR22650 3.2V 1800mAh 22.5*65.3 0.2-0.5C 0.2-3C 64 ≧2000
IFR26650 3.2V 3400mAh 26.5*65.3 0.2-0.5C 0.2-3C 85 ≧2000
IFR26650 3.2V 3600mAh 26.5*65.3 0.2-0.5C 0.2-3C 90 ≧2000
IFR26650 3.2V 3600mAh 26.5*65.3 0.2-0.5C 0.2-3C 90 ≧2000
IFR32700 3.2V 6000mAh 32.5*65.3 0.2-0.5C 0.2-3C 150 ≧2000
Why Choose Us
Technology
  • All-weather applicability (-30~60℃)
  • Highly safe battery design technology with the newest electrolyte and separator technology applied
  • Full Coverage of Battery Variety: Lithium ion Cylindrical battery, lithium polymer battery, LiFePO4 battery, Solar Energy Storage battery pack, square aluminum shell, Primary Battery, etc.
Research & Development

Experienced R&D team with over 60 engineers and advanced equipment for supporting OEM and ODM requirements.

3.2V LFP Battery with 2000 Cycles and Prismatic Design for EV and Solar Systems
Quality Control
3.2V LFP Battery with 2000 Cycles and Prismatic Design for EV and Solar Systems
Certifications

CE, RoHs, BIS, KC, CB, UL, MSDS, UN38.3, IEC61233 certificated.

3.2V LFP Battery with 2000 Cycles and Prismatic Design for EV and Solar Systems
Factory Tour

Shenzhen Gold Power Energy Co., Ltd is one of the leading battery suppliers in China. We have started to offer various batteries including Li polymer battery, Lithium ion battery, LiFePO4 battery, and customized battery pack since 2001.

3.2V LFP Battery with 2000 Cycles and Prismatic Design for EV and Solar Systems
