Specifications
Brand Name :
RanCheng
Model Number :
RCZ452T
Certification :
CE, ISO 9001:2000
Place of Origin :
China
MOQ :
1
Price :
$ 42000-45000
Payment Terms :
T/T, Western Union
Supply Ability :
100sets per Month
Delivery Time :
10-15 working days
Packaging Details :
Standard shipping
item :
RCZ452T hydraulic integrated DTH drilling rig
Model :
RCZ452T
Dimension(L*W*H) :
Motor, Engine, Gearbox
Drilling Diameter :
90-138mm
Drilling Depth :
21m
Type :
Rotary Drilling Rig
Description

Integrierter Typ Tragbares DTH-Bohr GeräT Mining Hard Rock Blast Hole Hydraulisches DTH-Bohr GeräT

Product Description

The RCZ452T compact hydraulic drill rig's integrated design improves productivity, eliminating the need for a traction air compressor, reducing air delivery losses and improving long-haul fleet management. Compared to split-body drill rigs, the diesel engine consumes 30% less energy and reduces maintenance costs by 50%. Key components from world-renowned brands are integrated. A single diesel engine drives both the rotary screw compressor and the hydraulic system, increasing power output.

Technical Parameters

item RCZ452T hydraulic integrated DTH drilling rig
Applicable Industries Energy & Mining, Construction works, Drilling
Weight 9220KG
Dimension(L*W*H) 9,000*2,360*3,000 mm
Core Components Motor, Engine, Gearbox
Drilling Diameter 90-138mm
Drilling Depth 21M
Type Rotary Drilling Rig
Power Type Diesel
Power Yuchai / 191 kW
Rotation Torque ( Max.) 2200 N.m
Rotation speed 0-115r/min
Air compressor FAD 17m3/min
Air compressor pressure 18bar
DTH hammer(Standard) 4"(inch)
Drilling rod 76*3,000 mm
Diesel tank volume 300 L
FAD 15 m³/min
Engine China III
Engine Model YCA07260T-301

Application

This hydraulic drilling rig is widely used in energy and mining, construction engineering, open pit blasting holes, quarry blasting hole drilling, highway blasting hole drilling, water conservancy, power station construction, railway and other construction drilling.
