Single Cylinder Piston Pump BW160H - 160L/Min Flow, 1.3MPa Pressure Mud Pump
Single Cylinder Piston Pump BW160H - 160L/Min Flow, 1.3MPa Pressure Mud Pump
Single Cylinder Piston Pump BW160H - 160L/Min Flow, 1.3MPa Pressure Mud Pump
Single Cylinder Piston Pump BW160H - 160L/Min Flow, 1.3MPa Pressure Mud Pump
Single Cylinder Piston Pump BW160H - 160L/Min Flow, 1.3MPa Pressure Mud Pump
Single Cylinder Piston Pump BW160H - 160L/Min Flow, 1.3MPa Pressure Mud Pump
Single Cylinder Piston Pump BW160H - 160L/Min Flow, 1.3MPa Pressure Mud Pump
Single Cylinder Piston Pump BW160H - 160L/Min Flow, 1.3MPa Pressure Mud Pump
Specifications
Brand Name :
RanCheng
Model Number :
BW160
Certification :
CE, ISO 9001:2000
Place of Origin :
China
MOQ :
1
Price :
USD2380
Payment Terms :
T/T, Western Union
Supply Ability :
100sets per Month
Delivery Time :
10-15 working days
Packaging Details :
Standard shipping
Model :
BW160
Flow rate :
160L/min
pressure :
1.3 mpa
Transmission power :
5.5KW
frequency of stroke :
147 times/min
Description
Single Cylinder Piston Pump BW160H - 160L/Min Flow, 1.3MPa Pressure Mud Pump
Product Specifications
Attribute Value
Model BW160
Flow rate 160L/min
Pressure 1.3 MPa
Transmission power 5.5KW
Frequency of stroke 147 times/min
Product Overview

The BW160 mud pump is a single-cylinder piston pump equipped with a single-cylinder diesel engine, operating in first gear at a constant speed. With a flow rate of 160 liters per minute and a maximum pressure of 1.3 MPa, it is primarily used in various drilling projects.

Technical Parameters
Parameter Value
Model No. BW160
Cylinder diameter 95mm
Piston Stroke 90mm
Frequency of stroke 147 times/min
Flow rate 160 L/min
Pressure 1.3 MPa
Power input 5.5 kW
Diameter of suction pipe 50mm
Diameter of discharge pipe 40mm
Overall dimensions (L×W×H) 850×600×550mm
Weight 130kg
Key Features
  • Compact design with small volume and light weight
  • Simple operation and easy relocation
  • Capable of transporting mud with sand content less than 5% or other liquids with pH value of about 7-8
Applications

The BW160 mud pump is a portable unit primarily designed to match with small-diameter geological exploration and engineering exploration drilling rigs with drilling depth of less than 300m.

Product Images
Single Cylinder Piston Pump BW160H - 160L/Min Flow, 1.3MPa Pressure Mud Pump Single Cylinder Piston Pump BW160H - 160L/Min Flow, 1.3MPa Pressure Mud Pump Single Cylinder Piston Pump BW160H - 160L/Min Flow, 1.3MPa Pressure Mud Pump Single Cylinder Piston Pump BW160H - 160L/Min Flow, 1.3MPa Pressure Mud Pump
