Specifications
Brand Name :
JINSP
Model Number :
SR100N25
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1
Price :
USD21900 - USD24300
Payment Terms :
T/T, Western Union
Supply Ability :
100PCS/40-60 days
Delivery Time :
30-40 working days
Packaging Details :
International Shipping Package
Sensing Area :
12.8mm*0.5mm
Wavelength Range :
900~2500nm
Entrance Slit Width :
5μm，10μm，25μm，50μm (customizable)
Incident Light Interface :
SMA905 fiber interface, free space
Description

900nm - 2500nm Near-Infrared Spectrometer

The JINSP SR100N25 near-infrared refrigerated spectrometers are versatileinstruments with applications spanning a broad wavelength range of 0.9 to 1.7μm or 0.9 to 2.5μm, respectively. These spectrometers are equipped with integrated light filters thateffectively screen out visible light and remove high-order modes. Additionally, they feature a cooled 512-pixel area array InGaAs sensor, ensuring high resolution and minimal stray of light. These spectrometers are suitable for detecting near-infrared spectra throughtransmission, reflection, or absorption methods.

Product Specifications:

Performance Indicators

SR100N25

Detector

Type

Refrigerated linear array InGaAs

Effective Pixel

512

Pixel Size

25μm*500μm

Sensing Area

12.8mm*0.5mm

Optical
Parameters

Wavelength Range

900-2500nm

Optical Resolution

6.3nm(@25μm)

Optical Design

F/4 cross-type

Numerical Aperture

0.14

Focal Length

100mm

Entrance Slit Width

5μm ,10μm ,25μm ,50μm (customizable)

Incident Light Interface

SMA905 fiber interface, free space

Electrical
Parameters

Integration Time

1ms-200ms

Data Output Interface

USB2.0 ,UART

ADC Bit Depth

16-bit

Power Supply

DC4.9 to 5.1V(type @5V)

Operating Current

＜3A

Operating Temperature

10°C~40°C

Storage Temperature

-20°C~60°C

Operating Humidity

＜90%RH (no condensation)

Physical
Parameters

Dimensions

178mm*123mm*49mm

Weight

1.2kg

Technical Characteristics:

  • 512 pixels, cooled type, high resolution, low stray of light
  • Receive SMA905 fiber input to obtain free space optical
  • Compatible with USB or UART interface to output measured spectrum data
  • Lens surface is plated with gold film, high efficiency of near-infrared reflection

Typical Applications:

  • Moisture content measurement and wastewater testing
  • Substance detection such as fat, oil, protein and fiber
  • Grain and fodder quality testing
  • Identification of illegal drugs components

Advanced Near Ir Spectrometer 5μM 10μM With 12.8mm*0.5mm Sensing Area

Advanced Near Ir Spectrometer 5μM 10μM With 12.8mm*0.5mm Sensing Area

Company Introduction:

JINSP Company Limited originates from Tsinghua University and has 17 years of experiences in developing spectroscopic technology.As a leading supplier of spectroscopic technology,JINSP Technology offers over twenty spectroscopic products across various fields, including pharmaceutical and chemical industries, public security and customs.

Our products mostly include:

--UV VIS NIR fiber optic spectrometers;

--Desktop/portable, online Raman analyzers for laboratory or indutrial liquid & gas analysis;

--On-site rapid detectors/identifiers based on Raman technology for drugs, liquid, food safety, explosive & hazardous materials, pharmaceutical industry etc;

Advanced Near Ir Spectrometer 5μM 10μM With 12.8mm*0.5mm Sensing AreaAdvanced Near Ir Spectrometer 5μM 10μM With 12.8mm*0.5mm Sensing Area

FAQ:

Q1:This is the first time I use,is it easy to operate?

A1:We will send you manual and guide vedio in English,it can teach you how to operate the spectrometer.Also our technicians will offer professional tecnical opearation meetings.

Q2:Can your offer a operation traning?
A2:Your technicians can come to our factory for a training. Jinsp engineers can go to your place for local support
( installation , training, debugging, maintenance ).

Q3:What's your website?
A3:You can visit:www.jinsptech.com

Q4:What about your quality assurance?

A4:We have a quality inspection team. All goods will go through quality inspection before shipment. We can send you pictures for inspection.
