Low-profile Anti-rust Perforated Raised Floor
Low-profile Anti-rust Perforated Raised Floor
Low-profile Anti-rust Perforated Raised Floor
Low-profile Anti-rust Perforated Raised Floor
Low-profile Anti-rust Perforated Raised Floor
Low-profile Anti-rust Perforated Raised Floor
Low-profile Anti-rust Perforated Raised Floor
Low-profile Anti-rust Perforated Raised Floor
Low-profile Anti-rust Perforated Raised Floor
Low-profile Anti-rust Perforated Raised Floor
Low-profile Anti-rust Perforated Raised Floor
Low-profile Anti-rust Perforated Raised Floor
Specifications
Place of Origin :
Changzhou City China
Brand Name :
FangSheng
Certification :
ISO9001
MOQ :
500 Square Meter/Square Meters
Packaging Details :
Wood pallet ,boxes
Delivery Time :
Prompt
Payment Terms :
T/T or L/C
Supply Ability :
2000㎡/Day
Description

Low-profile Anti-rust Perforated Raised Floor :
1.perforated panel
2.ventilationrate rate: 45%
3.Brand name:Fangsheng.

Perforated Raised Floor Description:

The structure of ventilation floor is similar with that of anti-static full-steel raised floor but it has hollow cavity without foam stuffing.The upper and lower steel paltes and upper cover of the floor are all punched with ventilation holes.Matched with the full-steel raised floor, the ventilation raised floor is used in the place where ventilation is required under the floor, and the ventilation rate of the floor is 17%-50%.

Perforated Raised Floor Character:

  • Size 600*600*35mm
  • Full steel. HPL or PVC punched tile
  • Surface punched panel which is hard steel of Shanghai Bao steel,
  • Manual welding for the bottom square tube. origination in domestic
  • Imported paint. Anti-rust
  • Prevent static validly fireproof, dustproof
  • Exact dimension for the hole of tile and panel .good ventilation function
  • 17 % - 50 % ventilation rate . Satisfies different environmental requirements

Technical parameter of Perforated Raised Floor:

Type

(mm)
Size

Concentrated Load
(deflection=2mm)

(N/M2)
Uniform Load

(N)
Ultimate limit Load

International

National Standard
SJ/T10796

lb

N

kg

AS450-TF

HDG600 30CQ

600×600×30

≥450

≥1960

≥200

≥8850

≥5900

≤17%

AS680-TF

HDG600 35QD

600×600×35

≥680

≥2950

≥300

≥12500

≥8250

≤25%

AS800-TF

HDG600 35QD

600×600×35

≥800

≥3550

≥360

≥15000

≥10650

≤25%

AS1000-TF

HDG600 35BD

600×600×35

≥1000

≥4450

≥450

≥23000

≥13350

≤36%

Notice: 1. It can arbitrary select the laying height of elevated floor.

2. The decorating surface of anti-electrostatic has high wearable melamine wainscot and PVC wainscot of made in
China , joint venture and export.

3. The carrying capacity of pedestal is over 20KN and can match with every type of elevated floor.

Use Area:

pc rooms, electricity office, information center, factory and ventilation area etc.

Install sample:
