High Reliability Railway Tank Wagons , Train Tank Car 80km/h Maximum Operating Speed
High Reliability Railway Tank Wagons , Train Tank Car 80km/h Maximum Operating Speed
Specifications
Brand Name :
Railteco
Place of Origin :
China
MOQ :
One pcs
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
According to customer's requirement
Delivery Time :
6 months
Packaging Details :
Railteco Standard Packing
Name :
Railway Tank Car
Payload :
43.6 T
Capacity :
27.5 m³
Maximum operating speed :
80 km/h
Feature :
Reliable
Track gauge :
As per client
Description

Railway Tank Wagons Phosphoric Acid Tank Wagon Railroad High-capacity Tank Car Mineral Oil Rail Tank Car

Parameters of Phosphoric Acid Tank Wagon:
Tare weight ≤17.4t
Payload 43.6t
Capacity 27.5m³
Axle load(bogie) 18t
Track gauge As per client­
Maximum operating speed 80km/h
Length over coupler 10530mm
R­min(single wagon) 70m
Break type UIC
Coupler type Screw coupler
Bogie type Cast type
Hydro test pressure 0.459MPa
Safety valve working pressure 0.15MPa
Type of load Top
Type of unload Bottom(both sides)

Description of Phosphoric Acid Tank Wagon:

Phosphoric acid tank Wagon is specially designed and manufactured to transport phosphoric acid. Loading hatches is covered with manhole cover, unloading hatches is equipped with one 5 inches internal valve, T branch pipe and two ball vales. The wagon is loaded from the top after the top cover is opened. Top cover is manually operated from wagon top platform. The wagon is unloaded from the bottom hatches. Internal valve and ball vale manually operated from both wagon sides, each ball vale separately. The goods are unloaded from two sides of wagon. The tank and tank fittings adopt 316L stainless steel. The wagon design meets the requirements of EN, UIC standard.

High Reliability Railway Tank Wagons , Train Tank Car 80km/h Maximum Operating Speed

High Reliability Railway Tank Wagons , Train Tank Car 80km/h Maximum Operating Speed

High Reliability Railway Tank Wagons , Train Tank Car 80km/h Maximum Operating Speed

High Reliability Railway Tank Wagons , Train Tank Car 80km/h Maximum Operating Speed
