Outdoor IP65 Metal Waterproof Access Control With Keypad Of Password
Outdoor IP65 Metal Waterproof Access Control With Keypad Of Password
Outdoor IP65 Metal Waterproof Access Control With Keypad Of Password
Outdoor IP65 Metal Waterproof Access Control With Keypad Of Password
Outdoor IP65 Metal Waterproof Access Control With Keypad Of Password
Outdoor IP65 Metal Waterproof Access Control With Keypad Of Password
Outdoor IP65 Metal Waterproof Access Control With Keypad Of Password
Outdoor IP65 Metal Waterproof Access Control With Keypad Of Password
Specifications
Brand Name :
A.N.G
Model Number :
AR-C30
Certification :
CE、FCC、ROHS
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T,Paypal,Western Union, MoneyGram
Supply Ability :
1000000
Delivery Time :
2-10Days
Packaging Details :
According to number of packages purchased
Price :
Depends on quantities
Item Type :
Access Control with Keypad
Material :
Novel metal
Capacity :
8000 user
Colour :
Red Bronze、Green Bronze、Gold、Silver、White Bronze
Size :
115*70*21mm
Working voltage :
DC9V-16V
Working frequency :
125kHz
open ways :
Card+Code
Description

Outdoor IP65 Metal Waterproof Access Control With Keypad Of Password

User registration
8000 user
Material
Zinc alloy,organic glass ( acrylic) faceplate.
Color
White bronze, Green bronze, Red bronze, Gold, Silver
Standard
FCC,CE,ROHS,appearance certification
Used
apartment,hotel,business building

Features:

  • Novel metal waterproof design, Acrylic scratch touch panel.
  • 8000 user capacity for storing and reading speed.
  • The same series of access control support data copy and backup.
  • Humanized tamper alarm function.
  • Can be used when the password read head and one machine.
  • WG26/34 input and output.
  • Can set up a management card.
  • Active and passive lock signal output.
  • Imported double point relay output signal.

Technical parameters

NO. Specification Parameter
1 Working voltage DC9V-16V
2 Static current ≤50MA
3 Storage capacity 8000 user cards
4 Reading distance 5-10cm
5 Working temperature -20℃-70℃
6 working humidity 0-95%

Function setting

Press"*",enter"123456#" or swipe systematic master card directly get to programming mode "0" Modify programming code and set master card
"1" Add card type use
"2" Add password type user
"3" Add password card type user
"4" Delete single user
"5" Delete all user
"6" Modify use password
"7" Modify delayed open door
"8" System initialization
"9" Set general opening password,add and delete card

Outdoor IP65 Metal Waterproof Access Control With Keypad Of Password

Outdoor IP65 Metal Waterproof Access Control With Keypad Of Password

Exquisite metal appearance design with smooth lines and chamfer;

Fire retardant effect; Touch scratch acrylic panel and backlit buttons, with waterproof function;

High-grade built-in microprocessor, with strong anti-interference ability, high security and reliability.

8000 user capacity storage and reading function;

The password of the 4-6 bit is more difficult to crack than the fixed number of passwords;

Three kinds of open form: password, credit ID card, password + ID card;

Add cards and delete cards, extended voice and other functions.

Size:

Outdoor IP65 Metal Waterproof Access Control With Keypad Of Password

4.Connection description

Red +12v Positive power
Black GND Negative power
Yellow NO Normally open ralay output
Gray COM Pubic relay port
Purple NC Normally closed relay output
Brown BTN Switch
Black GND Negative power
Green D0 Reading head signal-D0
White D1 Reading head signal-D1
Blue GLED Reading head signal-LED
Orange TXD Data copy
Pink RXD Data copy

Our Certifications

ISO9001,FCC,CE,ROHS,Product appearance certification.

If you are interested in this keypad, please welcome to send us an inquiry!
