Intelligent Electromagnetic Flowmeter | Industrial Electromagnetic Flow Meter Manufacturer

Specifications

Brand Name :

NUOYING

Model Number :

NYLD

Certification :

Place of Origin :

Xi'an, Shaanxi,China

MOQ :

1 pcs

Price :

Please Contact Me

Payment Terms :

T/T

Supply Ability :

1000 pcs/ pre month

Delivery Time :

7-15 working days

Packaging Details :

carton, 90cm×40cm×40cm

Product number :

NYLD

Grade :

Industrial

Warranty :

12 months

Customized support :

OEM, ODM

Media temperature :

-20 ~+90

Power supply :

220VAC/ 24VDC

Repeatability error :

±0.1% of the measured value

Protection grade :

Ip65, it can be customized up to IP68

Explosion-proof grade :

ExdllCT6

Output signal :

4-20mA (load resistance 0~750), pulse/frequency, control level

Conductivity range :

The conductivity ofthe measured fluid is ≥5μs/cm

Flow rate range :

0.1-10m/s

Description

strong anti-interference IP68 Intelligent Electromagnetic Flow Meter 0.1-10m/S 4-20mA

Name: Intelligent Electromagnetic Flowmeter Industrial Electromagnetic Flow Meter Manufacturer
Brand: NUOYING
Price: 1 USD

NYLD Electromagnetic Flow Meter

Products Description

NYLD Intelligent Eletromagnetic Flowmeter

The NYLD intelligent type electromagnetic flowmeter consists of a sensor and a converter. It is based on Faraday's law of
electromagnetic induction, which is used to measure the volume flow of conductive liquid with conductivity greater than 5μs/cm. It is an inductive meter for measuring the volume flow of conductive medium. In addition to measuring the volume flow of general conductive liquid, it can also be used to measure the volume flow of strong corrosive liquids such as strong acid and alkali and uniform liquid-solid two-phase suspension liquid such as slurry, pulp and paper pulp. It is wdely used for flow measurement of petroleum, chemical, metallurgy, textile, papermaking, environmental protection, food and other industrial sectors and municipal management, water conservancy construction, rivers and other fields.

Product Parameters

Intelligent Electromagnetic Flowmeter | Industrial Electromagnetic Flow Meter Manufacturer

Signal output	4-20mA (load resistance 0~750Ώ), pulse/frequency, control level
Conductivity range	The conductivity ofthe measured fluid is ≥5μs/cm
Communication output	Rs485 communication MODBUS protocol, HART communication interface
Output signal	4-20mA (load resistance 0~750Ώ), pulse/frequency, control level
Protection grade	Ip65, it can be customized up to IP68
Ambient Temperature	－25～＋60℃
Explosion-proof grade	ExdllСT6
