Electric Comfortable Compact SUV With Single Speed Gearbox
Electric Comfortable Compact SUV With Single Speed Gearbox
Electric Comfortable Compact SUV With Single Speed Gearbox
Electric Comfortable Compact SUV With Single Speed Gearbox
Electric Comfortable Compact SUV With Single Speed Gearbox
Electric Comfortable Compact SUV With Single Speed Gearbox
Specifications
Brand Name :
JAC VOLKS WAGEN SIHAO E20X
Model Number :
JAC VOLKS WAGEN SIHAO E20X
Place of Origin :
CHINA
MOQ :
1 unit
Price :
To be negotiated
Payment Terms :
L/C, T/T
Supply Ability :
100 per month
Delivery Time :
15 days
Packaging Details :
Length * width * height (mm)4135*1750*1565 Body structure5 door 5 seat SUV
Color :
red grey white black
Energy type :
Pure electric
level :
Small SUV
Pure electric range (km) :
402
manufacturer :
Jianghuai Dazhong
essential information :
Sihao e20x 2020 Xinsheng version
Description

JAC VOLKS WAGEN SIHAO E20X Transmission Case:Electric Vehicle Single Speed Gearbox

JAC VOLKS WAGEN SIHAO E20X
essential information Sihao e20x 2020 Xinsheng version
manufacturer Jianghuai Dazhong
level Small SUV
Energy type Pure electric
Environmental standards
Time to market 2019.09
Pure electric range (km) 402
Fast charging time (hours) 0.83
Slow charge time (hours) 8.5
Fast charge percentage 80
Maximum power (kw) 92
Maximum torque (n · m) 270
Motor (PS) 125
transmission case Electric vehicle single speed gearbox
Length * width * height (mm) 4135*1750*1565
Body structure 5 door 5 seat SUV
Maximum speed (km / h) 102
Official 0 ▬ 100km / h acceleration (s) ▬
Length (mm) 4135
Width (mm) 1750
Height (mm) 1565
Wheelbase (mm) 2490
Front track width (mm) ▬
Rear track width (mm) ▬
Minimum ground clearance (mm) 130
Body structure SUV
Number of doors (PCs.) 5
Number of seats (PCs.) 5
Oil tank volume (L) ▬
Luggage compartment volume (L) ▬
Curb weight (kg) 1480
Motor type Permanent magnet / synchronous
Total power of motor (kw) 92
Total torque of motor (n · m) 270
Maximum power of front motor (kw) 92
Maximum torque of front motor (n · m) 270
Maximum power of rear motor (kw) ▬
Maximum torque of rear motor (n · m) ▬
System comprehensive power (kw) ▬
System comprehensive torque (n · m) ▬
Number of drive motors Single motor
Motor layout Front
Battery type Ternary lithium battery
NEDC pure electric range (km) 402
Wltp pure electric range (km) ▬
CLTC pure electric range (km) ▬
Battery energy (KWH) 49.5
Fast charging time (hours) 0.83
Slow charge time (hours) 8.5
Fast charge (%) 80
Number of gears 1
Transmission type Fixed gear ratio transmission
Driving mode Front precursor
4WD form ▬
Center differential structure ▬
Front suspension type McPherson independent suspension
Rear suspension type Torsion beam dependent suspension
Boost type Electric power
Car body structure Bearing type
Front brake type Vented Disc
Rear brake type disc
Parking brake type Electronic parking
Front tire specification 205/55 R16
Rear tire specification 205/55 R16
Spare wheel specification
Active / passive safety equipment Standard ● optional ○ none ▬
Driver / passenger seat airbag ● main / auxiliary
Front / rear side airbag Front / rear
Front / rear head airbag (air curtain) Front / rear
knee airbag ▬
Passenger seat cushion airbag ▬
Rear seat belt airbag ▬
Rear seat anti slide airbag ▬
Rear central airbag ▬
Passive pedestrian protection ▬
Tire pressure monitoring function ● tire pressure display
Continue driving with zero tire pressure ▬
Seat belt not fastened reminder ● front row
ISOFIX child seat interface ●
ABS anti lock ●
Braking force distribution (EBD / CBC, etc.) ●
Brake assist (EBA / BAS / BA, etc.) ▬
Traction control (ASR / TCS / TRC, etc.) ▬
Body stability control (ESC / ESP / DSC, etc.) ▬
Parallel auxiliary ▬
Lane Departure Warning System ▬
Lane keeping assist system ▬
Road traffic sign recognition
Active braking / active safety system ▬
Night vision system ▬
Fatigue driving tips ▬
Auxiliary / control configuration Standard ● optional ○ none ▬
Front / rear parking radar Front ▬ / rear ●
Driving assistance image ● reversing image
Reverse vehicle side warning system ▬
Cruise system ▬
Driving mode switching ● movement

● economy
Automatic parking ▬
Automatic parking ●
Uphill assist ▬
Steep descent ▬
Variable suspension function ▬
air suspension ▬
Electromagnetic induction suspension ▬
Variable steering ratio ▬
Limited slip differential / differential lock ▬
Wade sensing system ▬
External / anti-theft configuration Standard ● optional ○ none ▬
Skylight type ▬
Sporty look Kit ▬
Rim material ● aluminum alloy
Electric pull in door ▬
Form of side sliding door ▬
Electric rear compartment ▬
Inductive rear compartment ▬
Electric rear compartment position memory ▬
The tailgate glass opens independently ▬
Roof luggage rack ●
Interior central lock ●
Key type ● remote key
Keyless start system ▬
Keyless entry function ▬
Active closed grille ▬
Remote start function ●
Side pedal ▬
Battery pre heating ▬
Internal configuration Standard ● optional ○ none ▬
Steering wheel material ● leather
Steering wheel position adjustment ● manual up and down adjustment
Multifunction steering wheel ●
Steering wheel shift ▬
Steering wheel heating ▬
Steering wheel memory ▬
Trip computer display screen ● color
Full LCD instrument panel ▬
LCD Meter size ● 7 inches
HUD head up digital display ▬
Built in dash cam ▬
Active noise reduction ▬
Mobile phone wireless charging function ▬
Electrically adjustable pedal ▬
Seat configuration Standard ● optional ○ none ▬
Seat material ● imitation leather
Sports style seat ▬
Main seat adjustment mode ● backrest adjustment

Adjustment before and after
Auxiliary seat adjustment mode ● backrest adjustment

Adjustment before and after
Electric adjustment of main / CO driver's seat Main / auxiliary
Front seat function ▬
Power seat memory function ▬
Front passenger seat rear adjustable button ▬
Second row seat adjustment ▬
Electric adjustment of rear seat ▬
Rear seat function ▬
Rear small table ▬
Second row independent seats ▬
Seat layout ▬
Rear seat recline form ● scale down
Rear seat power down ▬
Front / rear center armrest Front ● / rear ●
Rear cup holder ●
Heating / cooling cup holder ▬
Multimedia configuration Standard ● optional ○ none ▬
Central control color LCD screen ● touch LCD
Central control LCD size ● 8 inches
GPS navigation system ●
Navigation traffic information display ●
Road rescue call ▬
Split screen display of central control LCD ▬
Bluetooth / car phone ●
Mobile phone interconnection / mapping ● support carlife
Speech recognition control system ● multimedia system

● navigation

● telephone

● air conditioning
Gesture control ▬
Face recognition ▬
Vehicle networking ●
OTA upgrade ●
Car TV ▬
Rear LCD screen ▬
Rear control multimedia ▬
Multimedia / charging interface ●USB
Number of USB / type ▬ C interfaces ● 1 front / 1 Rear
Car CD / DVD ▬
220V / 230V power supply ▬
Luggage compartment 12V power interface ▬
Speaker brand name ▬
Number of speakers ● 6 horns
Light configuration Standard ● optional ○ none ▬
Low beam light source ●LED
High beam light source ●LED
Lighting features ▬
LED daytime running lights ●
Adaptive high and low beam ▬
Automatic headlamp ●
Steering assist lamp ●
Turn signal headlamp ▬
Front fog lamp ●LED
Headlamp rain fog mode ▬
Adjustable headlamp height ●
Headlamp cleaning device ▬
Headlamp delay off ●
Touch reading lamp ▬
Interior ambient light ▬
Front / rear power windows Both front and back
One button window lifting function Driving position
Window anti pinch function ▬
Multilayer sound insulation glass ▬
Exterior rearview mirror function Mirror heating

Electric regulation
Interior rearview mirror function Electric regulation
Rear windshield blind ▬
Rear side window blind ▬
Rear side privacy glass ▬
Interior vanity mirror copilot

Driver's seat
Rear wiper *
Inductive wiper function ▬
Heatable spray nozzle ▬
Air conditioner / refrigerator Standard configuration
Air conditioning temperature control mode Automatic air conditioning
Rear independent air conditioner ▬
Rear seat air outlet ▬
Temperature zoning control ▬
Car Purifier ▬
Interior PM25 filter unit ▬
Negative ion generator ▬
Interior fragrance device ▬
Car refrigerator ▬
