Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Specifications
Brand Name :
ShengFan
Model Number :
QSP-1703
Certification :
ISO9001 ROHS
Place of Origin :
Jiangsu, China
MOQ :
1PIECE
Price :
$2.00/pieces 1-49 pieces
Payment Terms :
L/C, T/T
Supply Ability :
10000 Piece/Pieces per Month
Delivery Time :
10-15days
Packaging Details :
plastic bubble/ polystyrene foam sheet/ carton/ wooden pallet
Type :
Clear Quartz Plate
Application :
Semiconductor, optical
Thickness :
0.5-100mm
Shape :
Square
Processing Service :
Punching, Cutting
product name :
Quartz Glass Plate
Material :
SIO2
SIO2 :
SIO2>99.99%
Density :
2.2g/cm3
Color :
Clear Transparent
Working temperature :
1100℃
Melting point :
1732℃
Port :
shanghai and Qindao port
Description
Laser cut small sized ultraviolet transparent fused quartz glass sheets for chamber windows
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Product Description
Clear Or Opaque Type Fused Silica Quartz Plate
We are a manufacturer of Quartz glass fused silica plate/sheet .
Size&design: Accept customize according to different diameter , thickness, length or sending your drawing.
Shengfan Quartz plate characteristic
*Brand
shengfanquartz
*SIO2
99.99%
*Density
2.2(g/cm³)
*Degree of hardness moh’ scale
6.6
*Melting point
1732℃
* Working temperature
1100℃
*Annealing point
1180℃
*Softening point
1630℃

Density 2.2x103 kg/m3 Hardness 5.5 - 6.5 Mohs' Scale 570 KHN 100
Design Tensile Strength 4.8x107 Pa (N/m2) (7000 psi) Design Compressive Strength Greater than 1.1 x l09 Pa (160,000 psi)SMD 5730
Bulk Modulus 3.7x1010 Pa (5.3x106 psi) Rigidity Modulus 3.1x1010 Pa (4.5x106 psi)
Softening Point 1730°C Annealing Point 1215°C
Setting Information
Color
Transparent
Shape
Circular / Round
Standard
JGS1,JGS2,JGS3
Material
99.99% sio2
Diameter
1-800mm
Thickness
0.2-100mm
Application
Optics quartz windows
Density
6.6
Light Transmittance
>92%
Hardness
Mose 6.5
Resistance Value
1000 times than ordinary glass

Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows

Product Display
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber WindowsLaser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber WindowsLaser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
【Application scope】:Used to make semiconductors, electric light source device, semi-conductor communication devices, lasers, optical instruments, laboratory instruments, electrical equipment, medical equipment and chemical instruments, chemical industry, electronics, metallurgy and other industries .
【Product advantages】: not easy to be corroded, can withstand high temperature, beautiful appearance, compact structure, easy to operate, strong light transmission, good electrical insulation.
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Production flow
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Product uses
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Packing
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Company Introduction
Laser Cut Small Sized Ultraviolet Transparent Fused Quartz Glass Sheets For Chamber Windows
Lianyungang Shengfan Quartz Products Co., Ltd.
Lianyungang Shengfan Quartz Product Factory is a professional manufacture specialized in research and development of quartz plate,quartz tube,quartz flange,quartz ring,cuvette and quartz instrument. The company is located in China Crystal Capital -Donghai City, Jiangsu Prov., China. 70 km far from Lianyungang port, convenient transportation. Covering an area of 1000 square meters,we now have over 30 employees,an annual sales figure exceeding USD 5.2 million. With the philosophy of Technology Orientation, Quality First,Integrity and Responsibility,Sustainable Operation, the company dedicates to estabinternational enterprise with standard and sustainable operation capability. Orientation, Quality First,Integrity and Responsibility,Sustainable Operation, the company dedicates to establish an international enterprise with standard and sustainable operation capability.

Our Services & StrengthThe company adhere to the integrity of business, experience, reasonable price, quality assurance, to provide excellent after-sales service, we sincerely welcome customers to come to negotiate

FAQ

Q1. Can I have a sample order? A: Yes, we welcome sample order to test and check quality. Q2. What about the delivery time? A:Within 15 days after receiving deposit. Q3. Do you have any MOQ limit? A: Low MOQ, 1pc for sample checking is available Q4. How to proceed an order in your factory? A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production. Q5. How do you ship the goods and how long does it take to arrive? DHL, UPS, FedEx or TNT are optional for small order. It usually takes 3-5 days to arrive. Airline and sea shipping are also available.
