High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications
High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications
High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications
High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications
High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications
High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications
High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications
High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications
Specifications
Brand Name :
shengfan
Model Number :
SF221012001
Certification :
ISO9001
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C,T/T
Supply Ability :
100,000 pieces per month
Delivery Time :
15 work days
Packaging Details :
plastic bubble/ polystyrene foam sheet/ carton/ wooden pallet
Name :
High transmittance Polished Quartz Glass Fire Pipe Semiconductor Protect Heat Resistant Vacuum Tube Transparent
Application :
Sources , Semiconductor
Material :
SIO2>99.99%
Feature :
Good Electrical Insulation
Light Transmittance :
>92%
Working Temparature :
1100℃
Hardness :
Mose 6.5
Resistance Value :
1000 times than ordinary glass
Color :
Transparent
Description
Heating Quartz Glass Tube - Transparent Semiconductor Grade with High Transmittance
High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications
Factory Price Transparent Heating Quartz Glass Tube
Premium electrical insulation quartz glass tube designed for light sources and semiconductor applications.
Primary Applications
Lighting systems, semiconductor manufacturing, optical communications, military equipment, building materials, chemical processing, mechanical components, electrical systems, and environmental protection applications.
Material Properties
  • Exceptional durability and structural integrity
  • Superior heat resistance performance
  • Excellent corrosion resistance
  • Low thermal expansion coefficient
Corrosion Resistant
Quartz glass exhibits no chemical reaction with acids except hydrofluoric acid. Its acid resistance is 30 times greater than ceramic and 150 times superior to stainless steel. The material maintains exceptional chemical stability at low temperatures, outperforming all other engineering materials.
Excellent Thermal Stability
The minimal thermal contraction coefficient enables quartz glass to withstand severe temperature variations. Quartz glass heated to 1100℃ will not fracture when immersed in cold water.
Superior Light Transmission
Quartz glass provides outstanding transmittance across all spectral bands from ultraviolet to infrared. Visible light transmittance exceeds 93%, with maximum ultraviolet spectral transmittance over 80%.
Premium Electrical Insulation
Electrical resistance of quartz glass is 10,000 times greater than ordinary glass, maintaining excellent electrical performance even at low temperatures.
Standard Clear Quartz Tube Applications
Halogen lamps, mercury lamps, single-end lamps, automotive lighting, stage lighting, thermoelectric boilers, photocopier lamps, water treatment lamp casings, quartz ware, and piping systems.
Shengfan Quartz Plate Technical Specifications
Parameter Specification
SiO₂ Content 99.9%
Density 2.2 g/cm³
Mohs Hardness 6.6
Melting Point 1732℃
Working Temperature 1100℃
Maximum Short-term Temperature 1450℃
Visible Light Transmittance Above 93%
UV Spectral Transmittance 80%
Annealing Point 1180℃
Softening Point 1630℃
Strain Point 1100℃
High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications
Company Profile
Lianyungang Shengfan Quartz Product Factory specializes in research, development, and manufacturing of quartz plates, quartz tubes, quartz flanges, quartz rings, cuvettes, and quartz instruments. Located in China's Crystal Capital - Donghai City, Jiangsu Province, our facility covers 1,000 square meters with over 30 employees and annual sales exceeding USD 5.2 million.
Guided by our philosophy of Technology Orientation, Quality First, Integrity and Responsibility, and Sustainable Operation, we are committed to establishing an international enterprise with standardized and sustainable operational capabilities.
Lianyungang Shengfan Quartz Products Co., Ltd
Mobile/WhatsApp: +8617696882108
Email: shengfanquartz@163.com
Address: Economic Development Zone, Donghai County, Lianyungang City, Jiangsu Province, China
High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications High Transmittance Heat Resistant Quartz Glass Tube with Good Electrical Insulation for Semiconductor Applications
