Qtenboard Round Display Series – Beyond the Frame, Defining the Future of Visual Display

Brand Vision: Form Meets Function, Design Meets Technology

Qtenboard redefines display possibilities through the fusion of innovative design and cutting-edge display technology. The Round Display Series was created to serve new demands for creative, non-traditional visual expression in modern commercial spaces — from retail and dining to cultural and public installations.
With two signature models — 15.7" RD157M and 23.6" RD236M — Qtenboard breaks away from rectangular norms, offering brands a new medium for memorable storytelling and aesthetic differentiation.

Product Overview: Two Circular Displays, Infinite Scenarios

15.7-inch (Model RD157M)
Compact and stylish, ideal for counters and embedded displays. Perfect for jewelry showrooms, cafés, or smart device terminals.

23.6-inch (Model RD236M)
Elegant and striking, suitable for wall or column installation in malls, restaurants, and exhibition venues.

Both sizes embody a seamless balance between form and function, transforming every viewing angle into a work of art.

Key Features

1. Custom Circular Resolution – Perfect Geometry, No Cropping

Unlike traditional square panels cropped into circles, Qtenboard employs fully customized circular LCD panels.

• RD157M: 960×960 resolution – crisp details for compact displays.

• RD236M: 1280×1280 resolution – vivid clarity for larger visuals.

Every pixel is designed for a flawless circular presentation.

2. 1500 Nits Brightness + High-Haze Panel – Always Clear, Always Brilliant

Engineered for high-traffic environments:

• 1500 nits brightness keeps visuals bright even in sunlight or showcase windows.

• High-haze coating (>30%) reduces glare and reflection, maintaining excellent visibility from all angles.

3. Android Smart System + HDMI Input – Smart Control, Flexible Connectivity

The built-in Android system supports app downloads, custom UI design, and media playback, while HDMI input connects seamlessly to PCs or media boxes.
This dual-mode flexibility allows for standalone operation or integrated display networks.

4. Industrial-Grade Durability – Designed for 24/7 Operation

Made for continuous commercial use:

• Full metal frame + 2.5D tempered glass for strength and style.

• Low power design, 0℃–45℃ operation range.

• Optional IP54 protection for restaurants and semi-outdoor environments.

Technical Specifications

Application Scenarios

Retail:
Highlight brand uniqueness. Display product details or storytelling videos in luxury boutiques or digital stores.

Catering:
Bring creativity to the dining experience. Use as circular menu screens or ambient brand displays.

Culture & Service:
Enhance visitor experience in museums, galleries, or service halls with artistic navigation and information screens.

FAQ

Q: Is 1500 nits brightness suitable for outdoor use?
A: Yes, it ensures clarity in semi-outdoor areas like shaded terraces or storefronts.

Q: What resolution content works best?
A: Match the native panel resolutions — RD157M (960×960), RD236M (1280×1280).

Q: Can it operate continuously in warm environments?
A: Yes, it supports 0–45℃ operation. Ensure ventilation in enclosed areas.
