Specifications
Brand Name :
WINCOO
Model Number :
MSHW
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 unit
Price :
USD 5000~12000
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
230 Set/Year
Delivery Time :
45 working days
Packaging Details :
Export package
Model NO. :
MSHW
Keywords :
Tank Vertical Welding Machine
Plate Thickness :
8~45mm
Plate Material :
Carbon Steel, Stainless Steel
Welding Process :
Saw
Transport Package :
Container
Specification :
SGS, ISO9001, CE
Trademark :
WINCOO
Origin :
Nanjing, China
HS Code :
851531900
Cooling Way :
Water Cooling
Control :
Semi-Automatic
Style :
Hanging
Frequency Range :
Intermediate Frequency
Electric Current :
Inverter
Type :
Continuous Seam Welder
Customization :
Available | Customized Request
Description

Product Introduction:
The EGW Series revolutionizes vertical welding for ultra-thick storage tanks (e.g., LNG, LPG, cryogenic vessels). Featuring dual-wire tandem EGW technology, it achieves deposition rates exceeding 25 kg/h (55 lbs/h), welding plates up to 100mm thick in a single pass. Integrated oscillation and real-time seam tracking ensure flawless fusion in critical applications requiring ASME Section VIII or API 620 compliance. Ideal for shipyards and heavy fabrication shops.

Key Specifications:

Parameter Specification
Welding Process Tandem Electrogas Welding
Plate Thickness 20 mm – 100 mm (0.79" – 3.94")
Deposition Rate 22 – 30 kg/h (48 – 66 lbs/h)
Wires 2 x 2.4 mm or 3.2 mm
Oscillation ±30 mm (servo-controlled)
Travel Control Laser seam tracking + Encoder feedback
Voltage/Current 35–50V DC / 2x 400–750A
Gas System Dual-zone gas shielding (Ar/He/CO₂)
Data Logging Weld parameter recording (ISO 3834)
Power Supply 480V AC, 3-Phase, 200 kVA

Key Features:

  • Industry-Leading Speed: 2x productivity vs. standard EGW for thick sections.

  • Deep Penetration: Dual-arc synergy ensures full fusion on 100mm plates.

  • Active Arc Control: Independent parameter adjustment for each wire.

  • Zero-Defect Guarantee: Auto-correction via seam tracking & oscillation.

  • Remote Monitoring: Real-time weld analytics via IoT interface.

  • Cryogenic-Ready: Optimized for 9% Ni steel, stainless steels, and aluminum alloys.Advanced EGW Vertical Seam Welding Machine for Thick-Wall Tanks

Application Scenarios:

  • LNG/LPG storage tanks (API 620, Appendix Q).

  • Cryogenic vessels (-196°C service).

  • Thick-wall reactor shells in petrochemical plants.

  • Nuclear waste containment tanks.

  • Offshore platform leg sections & gravity-based structures.
