Specifications
Brand Name :
WINCOO
Model Number :
WHL-III
Certification :
CE,CCC
Place of Origin :
CHINA
MOQ :
1 set
Price :
USD+1800~4680+set
Payment Terms :
L/C,D/P,T/T
Supply Ability :
100 set/month
Delivery Time :
30 days
Packaging Details :
Export package
After-sales service provided :
Engineers available to service machinery overseas,Video technical support
Voltage :
380v/50hz or customized
Usage :
Carbon Steel welding,seam welding of metal material.
Description

Product Description:
The WHL-III Series is a lightweight, modular solution for vertical welding of storage tanks during on-site erection. Using gas-shielded flux-cored (FCAW-G) or metal-cored (MCAW) wires, it delivers high-speed, all-position welds without complex EGW setups. Magnetic clamps and telescoping rails enable rapid deployment on curved surfaces, making it ideal for remote tank farms, wind tower sections, and repair projects.

Cheap Portable Vertical MIG Welding Tractor for Tank Construction

Key Specifications:

Parameter Specification
Welding Process Pulsed MIG/MCAW/FCAW-G
Plate Thickness 6 mm – 25 mm (0.24" – 1")
Travel Speed 200–600 mm/min (8–24 in/min)
Wire Feed 5–25 m/min (16–82 ft/min)
Clamping Force Electromagnetic (10,000 N)
Weight 65 kg (143 lbs)
Power Source 230V/460V inverter (synergic control)
Curvature Range Tanks ≥ 8m diameter (26 ft)
Environment IP54 rated (dust/water resistant)

Key Features:

  • Rapid Deployment: Modular tracks assemble in <30 mins; no cranes needed.

  • All-Position Capable: Welds vertical-up, horizontal, and overhead seams.

  • Wind Tolerance: Gas-shielded FCAW performs in outdoor conditions.

  • Battery Backup: 1-hour UPS for grid instability.

  • Low Spatter: Synergic pulsed MIG reduces cleanup.

  • Cost-Effective: 40% lower capex vs. EGW systems.

Cheap Portable Vertical MIG Welding Tractor for Tank Construction

Application Scenarios:

  • Field erection of oil/water tanks (API 650).

  • Wind turbine tower sections.

  • Grain silo assembly & cement storage bins.

  • Tank repair (external shell welds).

  • Modular refinery construction.

  • Cheap Portable Vertical MIG Welding Tractor for Tank Construction
