Product Introduction

The Crawling-Type CNC Pipe Intersection Cutting Machine is an advanced automated solution designed for precision cutting of complex intersecting profiles (e.g., Y, K, T joints) in pipes and tubes. Its unique crawling mechanism allows it to move along the pipe’s surface, enabling on-site or workshop-based cutting without fixed mounting.

Start of cutting

Cut halfway through

After one round of cutting

Finished cutting

Product Parameter

• Pipe Diameter Range: Ø60–Ø1500 mm

• Wall Thickness: Up to 50 mm (dependent on cutting method)

• Cutting Methods: Plasma, Oxy-Fuel, or Laser

• Positioning Accuracy: ±0.5 mm

• Bevel Angle Range: 0–60°

• Power Supply: 220V/380V AC

• Control System: Industrial PC with CAD/CAM software

Product Features

1, 360° Rotary Cutting Head: Cuts any angle or shape around the pipe circumference.

2, Clamp-Free Design: Magnetic or chain-driven crawling system adapts to curved surfaces.

3, Offline Programming: Import 3D models (DXF, SAT) to auto-generate cutting paths.

4, Automatic Bevel Compensation: Adjusts torch angle for perfect weld-ready joints.

5, Dust Extraction Port: Integrated fume management

Product Advantages

Portability: Ideal for field operations (construction sites, shipyards).

Material Savings: Optimizes nesting, reducing waste by 15–30%.

High Efficiency: 3–5× faster than manual cutting.

Minimal Setup: No pipe rotation or fixturing required.

Weld-Ready Edges: Beveled cuts eliminate post-processing.

Applications

Offshore Platforms: Pipe railing, structural nodes.

Shipbuilding: Hull pipelines, ventilation systems.

Power Plants: Boiler tube networks, pressure vessels.

Architecture: Steel art installations, space frames.

Product Photos

In conclusion, a portable plasma flame pipe cutting machine is a valuable cutting tool that can save time, effort, and money. It is versatile, efficient, precise, and can be automated, making it an ideal cutting tool for various industries. By understanding its components and features, you can determine if it is the right cutting tool for your needs.
