Specifications
Place of Origin :
Jiangsu, China
Brand Name :
WINCOO
Packaging Details :
Export package
Supply Ability :
3000 Set/Sets per Month
Price :
$116,800.00/sets 1-99 sets
Condition :
New
Warranty :
1 Year
Applicable Industries :
Manufacturing Plant, Construction works
Weight (KG) :
13000
Showroom Location :
None
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2022
Warranty of core components :
1 Year
Core Components :
Engine, Gearbox, Motor, Pump
UNIQUE SELLING POINT :
High operating efficiency
Product name :
Medium Frequency Heating Tractor
Application :
Pipeline constructure
After-sales Service Provided :
VIDEO SUPPORT
Keywords :
Pipeline heating machine
Description

WINCOO ENGINEERING CO.,LTD
Wincoo Engineering Co., Ltd (WINCOO) is engaged in bringing the most suitable solutions/equipment for client, fabricators, EPC/C companies on pipe fabrication, tank construction, pipeline construction, industrial production lines, clean energy project and other industrial field.
Medium Frequency Heating Tractor Paywelder for Fast Pipeline Construction
Medium Frequency Heating Tractor is Pipe heating before pipe welding. It has the ability to work in the wild (plateau, mountain, desert, loose soil, water network and cold zone). Walking ability, power generation capacity, pipeline heating capacity, crane working ability, all are excellent.
The machine is an addition to the HG series of mobile power stations with medium frequency heating machine.
Medium Frequency Heating Tractor Paywelder for Fast Pipeline Construction
Product Features
Crawler walking Tractor,Using hydraulic drive,Max climb capability 25°；The brake system uses the world's most advanced controls.
Medium Frequency Heating power supply use IGBT Inverter power supply, Air cooling. Inverter power supply: work and power, temperature co-movement is very well. Accurate and stable control of heating temperature through automatic power and temperature control system. The variable frequency power supply has the function of variable frequency/load change adaptation, which can maintain the best matching state between the power supply and the workpiece, including no-load operation. The built-in intelligent control system and external thermocouple or infrared thermometer feedback excellent cooperation, can easily adjust the temperature or power-time parameters, rapid temperature rise and uniform heating, can also flexibly adjust the temperature curve temperature control, can accurately control the heating process, the heat preservation process (It can be kept for a long time).
The intelligent protection system intelligently protects people and equipment. The industrial touch screen display displays and maintains a communication interface in real time. The power factor is always maintained at 0.95 regardless of the power. The power supply is automatically adjustable and the startup success rate is 100%.
Product Parameters
Model
HGZ160
Operating weight
11.5T
Dimensions((L×W×H)
4950x2680x3340 mm
Engine
Model
Cummins
Rated power
153 kW/2200 rpm
Generator
Model
UCI274F STF
Kilo Volt-Ampere
160 kVA
Power supply
Rated power
80 kW(100KW,120KW,160KW Optional)
Power scope
10%—100%
Walking system
Model
Track, Automatic hydraulic working mode
Max. Walking speed
Two-speed, continuously variable CVT 1.9/3km/h
Max. climbing angle
25°
Minimum ground clearance
490 mm
Track width
600 mm
Crane system
Model
Rotary, Automatic arm
Max. lift weight
3.2t
Moment of lifting
6t.m
Rotary
360°
Product Major Component
Medium Frequency Heating Tractor include: Crawler walking Tractor; Medium Frequency Heating power supply; Medium Frequency inductorium; Thermostat; Generator； Crane and Engine.
Product Photos
Medium Frequency Heating Tractor Paywelder for Fast Pipeline Construction
Medium Frequency Heating Tractor Paywelder for Fast Pipeline Construction
Medium Frequency Heating Tractor Paywelder for Fast Pipeline Construction
Medium Frequency Heating Tractor Paywelder for Fast Pipeline Construction
Medium Frequency Heating Tractor Paywelder for Fast Pipeline Construction
Medium Frequency Heating Tractor Paywelder for Fast Pipeline Construction
Medium Frequency Heating Tractor Paywelder for Fast Pipeline Construction
Medium Frequency Heating Tractor Paywelder for Fast Pipeline Construction
Medium Frequency Heating Tractor Paywelder for Fast Pipeline Construction
Medium Frequency Heating Tractor Paywelder for Fast Pipeline Construction
Wincoo Engineering Co., Ltd (WINCOO) is engaged in bringing the most suitable solutions/equipments for client, fabricators, EPC/C companies on pipe fabrication, tank construction, pipeline construction,industrial production lines, clean energy project and other industrial field.

Our Services & Strength
We have ability of providing workable solutions to support clients to be awarded with shorter project execution time, fewer man-hour cost and higher efficiency construction/fabrication method and better quality during phase of project bidding.

Based client’s facility/site space availability, we are able to study/design and present matched configurations on project schedule, quality, cost and productivity to guarantee production pace is accordance with project requirement.

To support project execution, we are always ready to work as fireman to give prompt supply on project materials from different consumables, tools, equipments/machines to special merchandise. With flexibility, we are also glad to perform as procurement agent in China to seek required supply resources.
